Result (example):
STEP 5: Closing off unused cable passages
STEP 6: Attaching the cable cover
Dummy grommets
− Close off all unused cable
passages with dummy grommets
so that they are sealed.
− Place the cable cover on the
DLT-V6210 housing slot.
− Use 4 pcs of Phillips Screws M3x5L:
− Lock the screws loosely into the holes
of the cable cover.
− Then fully tighten the screws
alternatingly with 1 Nm torque.
11
