General ACM200 Commands
COMMAND DESCRIPTION
Print all available commands of ACM200
Turn IR control port On or Off
Turn On Serial Guest Mode to Receiver (output)
(NOTE: This only puts the RX into Serial Guest
mode but doesn't open the connection. Please use
command below)
br =0: 300
br=1: 600
br=2:1200
br=3: 2400
br=4: 4800
br=5: 9600
br=6: 19200
br=7: 38400
br=8: 57600
br=9: 115200
bit= Data Bits + Parity + Stop Bits
Example: 8n1
Data Bits=[5...8], Parity=[n o e], Stop
Bits=[1..2]
Serial Guest Mode to Transmitter (input)
(details as above)
Start Serial Guest Mode To Output
Start Serial Guest Mode To Input
Close Serial Guest Mode
Set IO ports for use as input or output port
gg=0: select all ports
gg=01...04: select single IO port
Set IO port to low(0) or high(1) level
Get IO port real input level
IO port status
System status summary
When command fails
contact
support@blustream.co.uk / support@blustream.com.au
HELP
IRON/OFF
OUTxxxSGON/OFF[br][bit] Set serial guest mode config done
INxxxSGON/OFF[br][bit]
ooo OUT ooo
ooo IN ooo
CLOSEACMGUEST
GPIOggDIRIN/OUT
GPIOggSET0/1
GPIOggGET
GPIOggSTATUS
STATUS
COMMAND
(See HELP summary at end)
Set IR
Set serial guest mode config done
GUEST (no feedback when in guest mode)
GUEST (no feedback when in guest mode)
[Success] Exit guest
Set GPIO gg as
Get GPIO gg real input level
(See status example at end of document)
(See status example at end of document)
unkown param. Type "HELP" for more reference
Output xxx does not exist
configured)
Input yyy does not exist
figured)
Output xxx is offline
Input yyy is offline
Param range error
ACM200
RESPONSE
ON/OFF
input/output port
0/1
(RX has not been
(TX has not been con-
(outside of given settings)
