- Page 1 Dionex SRD-10 Suppressor Regenerant Detector Installation Instructions Document No. 065355 Revision 04 May 2018...
- Page 2 © 2018 Thermo Fisher Scientific Inc. All rights reserved. Chromeleon and SRS are registered trademarks of Thermo Fisher Scientific Inc. in the United States. All other trademarks are the property of Thermo Fisher Scientific and its subsidiaries. Thermo Fisher Scientific Inc. provides this document to its customers with a product purchase to use in the product operation.
-
Page 3: Dionex Srd-10 Installation Instructions
Dionex SRD-10 Installation Instructions Overview ™ ™ The Thermo Scientific Dionex SRD-10 Suppressor Regenerant Detector (P/N 074395) is a stand-alone device that monitors liquid flow to a suppressor and signals when to replenish the regenerant or external water supply. If the flow is restricted or stops, the Dionex SRD-10 automatically disables the eluent pump. - Page 4 Dionex SRD-10 Installation Instructions TTL Control In order to control the eluent pump, the Dionex SRD-10 must be connected to a TTL input on one of the following Thermo Scientific products: Integrated IC Systems Pump Modules Dionex ICS-1100, ICS-1600, or ICS-...
-
Page 5: Installation
1, View A) to the port on the suppressor. REGEN OUT View B View A Inlet Tubing Waste Line TTL Output USB Port Hook-and-loop strip (1 of 3) Figure 1. Thermo Scientific Dionex SRD-10 Suppressor Regenerant Detector Doc. 065355-04 05/18... - Page 6 Dionex SRD-10 Installation Instructions 3. Place the free end of the Dionex SRD-10 line (see Figure 1, View A) WASTE in a waste container below the level of the workbench on which the IC system is installed. 4. Remove the backing from the three hook-and-loop strips on the Dionex SRD- 10 (see Figure 1, View B).
-
Page 7: Chromeleon Setup
Dionex SRD-10 Installation Instructions c. Connect the wires from the Dionex SRD-10 connector plug to the TTL connector pins on the other device. NOTE Check the polarity of the connection. Connect the signal wire to the signal (+) pin and the ground wire to the ground (-) pin. - Page 8 Dionex SRD-10 Installation Instructions Chromeleon 7: Pump Setup Start the Instrument Configuration Program 1. Stop all batches, programs, and data acquisition events on the Chromeleon Controller that hosts the pump to be updated. 2. If it is not already running, start the Instrument Controller Service. (Click Start >...
- Page 9 Dionex SRD-10 Installation Instructions If the pump is a Dionex ICS-3000 DP or ICS-3000 SP, go to the next section to update the firmware. If the pump is not a Dionex ICS-3000 DP or ICS-3000 SP, go to page 8 configure the pump TTLs.
- Page 10 Dionex SRD-10 Installation Instructions b. Insert the Dionex ICS-3000 Dual Pump/ICS-3000 Single Pump Firmware CD into the appropriate drive. c. Copy the pump firmware file from the CD to the \Bin directory of your Chromeleon installation. 3. Click Install Firmware again. When the notification of the installed firmware version appears, click Yes to update the firmware.
- Page 11 Dionex SRD-10 Installation Instructions 2. Click OK. 3. Exit the Instrument Configuration program. When asked whether to save the configuration changes, click Save. This completes the pump setup. Go on to Section Chromeleon 6.8: Pump Setup Start the Server Configuration Program 1.
- Page 12 Dionex SRD-10 Installation Instructions If the pump is a Dionex ICS-3000 DP or ICS-3000 SP, go to the next section to update the firmware. If the pump is not a Dionex ICS-3000 DP or ICS-3000 SP, go to page 11 to configure the pump TTLs.
- Page 13 Dionex SRD-10 Installation Instructions b. Insert the Dionex ICS-3000 Dual Pump/ICS-3000 Single Pump Firmware CD into the appropriate drive. c. Copy the pump firmware file from the CD to the \Bin directory of your Chromeleon installation. 3. Click Install Firmware again. When the notification of the installed firmware version appears, click Yes to update the firmware.
-
Page 14: Routine Operation
Dionex SRD-10 Installation Instructions 2. Click OK. 3. Exit the Server Configuration program. When asked whether to save the configuration changes, click Save. This completes the pump setup. Go on to Section Routine Operation Before starting an analysis, wait about 10 seconds to allow the Dionex SRD-10 to automatically switch to operating mode.
