Bosch Access Easy Controller 2.1 Hardware Installation Manual page 5

Access Easy Controller 2.1
16.2 Before Starting the Update
16.3 Recovering Controller Database from a Windows Computer
17
Entry and Arm/Disarm Reader
17.1 Wiring diagram of a HID Compliant Entry and Arm/Disarm Reader
18
Appendix A How to Install & Set the TCP/IP Address on a PC
19 Appendix B Modem Setup
19.1 Preparing the WAVECOM GSM Modem for AEC2.1
19.2 How to Test the GSM Modem
20 Appendix C Detailed Wiring
21
Appendix D Selecting A Correct Battery Size
21.1 Battery Specification for Access Easy Controller 2.1
22 Appendix E Troubleshooting
22.1 Login Problems
22.2 Network Connectivity Problems
23 Appendix F Frequently Asked Questions
23.1 General Questions
23.2 Controller Questions
23.3 Reader and Door Questions
23.4 Inputs and Outputs
23.5 Network Question
24 Appendix G Blank Configuration Form
25 Appendix H Resetting to Factory Default
25.1 Resetting to Factory Default
25.2 Resetting IP Address to Default IP Address
26
Appendix I Ports Used by AEC2.1 and AEMC
Robert Bosch (SEA) Pte Ltd Hardware Installation Manual
Table of contents | en 5
96
96
98
100
101
105
105
106
108
111
111
114
114
115
120
120
122
123
125
125
127
130
131
132
133
2018.11 | 1.0.6 | F.01U.122.796
