Access Easy Controller 2.1
Refer to Appendix H Resetting to Factory Default, page 130 for detail instructions.
Jumper Link to reset
to factory default
Figure 6.8: Factory Default Setting
Caution!
Resetting the system to factory default settings will clear the data stored in the AEC2.1
system. Be sure to do a backup of the system before resetting.
!
After rebooting the system, remove the jumper links from the 4-Reader board.
This function is only available to the first 4-Reader board of the AEC2.1 configuration,
although all the 4-Reader board comes with JP2.
Robert Bosch (SEA) Pte Ltd
JP2
Hardware Installation Manual
4-Reader Board | en
Jumper Link to
reset IP address
