Chapter 2: External Connectors Pinout Description
Line-out
Connector Number: 12
Pin
Definition
1
Line2 LC
3
NC
5
GND
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
Line2 JD
4
Line2 RC
6
GND
Mic-in
Connector Number: 13
Pin
Definition
1
Mic1 C
3
NC
5
GND
13
Pin
Definition
2
Mic2 JD
4
Mic1 CL
6
GND
VTC 1010 User Manual
