Programs - Whirlpool VAN GOGH WWD22ABBPH00 Service Manual

Dual inlet
Hide thumbs

Advertisement

Water Level Key
Defines High and Medium levels by means of a Pressure Switch. The
function of this component can be checked in the topic 5.4 – Pressure
Switch.
When the Led is lighted, the washer intend Medium level, therefore, it is light
off , intend High level.
Select/Advance Program Key
This key define programs types as: Super Wash, Regular Wash, Fast Wash and
Spin.
Each touch on this Key select a different Program.
4.2 – Programs
In order to perform Washer programming, the Consumer has the option to select the adequate program for
their use, that can perform as follows:
a) Water Level
At every touch on the Medium Water Level key a new Water level will be selected. When the Led is lighted,
the washer intend Medium level, therefore, it is light off , High level will be in progress.
b) Rinse
This washer define rinses quantity automatically by the selection programs, as follows:
Program
SUPER WASHING
REGULAR WASHING
FAST WASHING
c) Washing Main Program selection
The washing programs available in this function are: Super Wash, Regular Wash and Fast Wash.
Select the washing program for each appropriate use. Dirty level needs to be considered as follows:

PROGRAMS

SUPER WASHING
REGULAR WASHING
FAST WASHING
MSEX0060i
Rinses Quantity
2 Rinses
2 Rinses
1 Rinse
Clothes Condition
Very dirty clothes
Dirty clothes
Little dirty clothes
9
