2.3 Water Consumption (liters)
PROGRAMS
SUPER WASH
REGULAR WASH
FAST WASH
Note: Programming Time may vary according to the Water Pressure Variation.

2.4 Programming Time

CYCLES
RECOMMENDATION
SUPER WASH
REGULAR WASH
FAST WASH
SPIN
(*) Time periods considering High Water Level.
Programming Time may vary according to Water Pressure Variation

3 - INSTALLATION

3.1. Hydraulic

HEIGHT *

3.2 Electric

The unit must be connected to an exclusive outlet (never use any extension wires or plugs).
A 10A Thermal Circuit Breaker must also be used in each phase, besides the Earth Wire connection.
Never change the Power Cord with a non-recommended component, neither eliminate grounding terminal.
Both of these actions may cause damages.
MSEX0060i
DIRTY LEVEL
Very dirty
Dirty
Little dirty
Not Applicable
IMPORTANT:
•
•
•
WWD22A
WATER LEVEL
HIGH
252
251
187
WASHING STEPS
SOAK
WASH RINSE
yes
yes
yes
no
yes
yes
no
yes
yes
no
no
no
Make sure that there is a BSP ¾" x 11,5 threaded tap
exclusively for the Washer connection.
The water pressure in such tap shall be between 19,6 Kpa
and 784,5 Kpa.
There must be also a device for water drainage, such as
a Tub or an exclusive pipe with 5-cm diameter and a height
between 85cm and 120cm.
* HEIGHT OF OUTLET SIPHON
WATER SUPPLY PRESSURE
MEDIUM
173
171
135
APPROXIMATED
TIME PERIOD (*)
SPIN
WWD22ABBPH
yes
1h35min
yes
48min
yes
36min
yes
05min
MINIMUM
0.85 m
0.2 kgf/cm2
MAXIMUM
1.20 m
8 kgf/cm2
5
