5.15 – Mechanical Set
In the figure below we can see the components of the Gearcase Assembly
Under the Motor Support, we can see the follow components
MSEX0060i
D – Spring, Splutch
E – Slider, Splutch
F – Cam Ring, Splutch
G – Cam, Splutch
H – Pulley Drive
I – Nut
J – Belt Driver
A - Gearcase Set, Assembly
B - Motor Support
C - Spring, Brake
E
G
J
D
F
H
I
24
