Signal and port names are shown in lowercase Courier type. Examples:
, Active-low signals are denoted by suffix
tdi input.
Anything that must be typed exactly as it appears is shown in Courier type. For
example: c:\qdesigns\tutorial\chiptrip.gdf
actual file, such as a Report File, references to parts of files (e.g., the AHDL
keyword SUBDESIGN ), as well as logic function names (e.g.,
Courier.
Numbered steps are used in a list of items when the sequence of the items is
important, such as the steps listed in a procedure.
Bullets are used in a list of items when the sequence of the items is not important.
The checkmark indicates a procedure that consists of one step only.
The hand points to information that requires special attention.
The caution indicates required information that needs special consideration and
understanding and should be read prior to starting or continuing with the
procedure or process.
The warning indicates information that should be read prior to starting or
continuing the procedure or processes
The angled arrow indicates you should press the Enter key.
The feet direct you to more information on a particular topic.
