Component List

Cyclone II
EP2C20 FPGA
Altera Corporation
October 2006
The development board comprises the following major components:
■
Altera Cyclone II EP2C20 FPGA
■
Altera USB-Blaster controller chip set
■
Altera EPCS4 configuration device
■
VGA DAC
■
24-bit Audio CODEC
■
Memory
8 MByte SDRAM
●
512 KByte SRAM
●
4 MByte flash memory
●
■
Internal dual clock circuit
■
Switches
Power ON/OFF switch
●
RUN/PROG mode selector switch
●
4 momentary push button switches
●
10 sliding toggle switches
●
■
Displays
LEDs: 8 green, 10 red
●
4 seven-segment displays
●
■
Connectors
USB-Blaster port
●
Two, 40-pin expansion headers
●
SD card connector
●
RS-232 serial port
●
PS/2 port
●
VGA video port
●
Audio microphone-in, line-in, line-out ports
●
SMA external clock connector
●
7.5 V power supply connector
●
The main device that defines the starter development board is an Altera
Cyclone II EP2C20 FPGA in a 484-pin FineLine BGA
lists the FPGA features.
Table 2–1. Cyclone II EP2C20 FPGA Features (Part 1 of 2)
LEs
M4K Memory Blocks
2. Development Board
Components
18,752
52
®
package. Table 2–1
