2 Appendix
CONNECTOR
* Depends on the model
Configuration Interface
LOCAL TERMINAL
CONNECTOR
Power Source
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
MAXIMUM POWER
APPROX CONSUMPTION.
Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
Environmental Specifications
AMBIENT TEMPERATURE
RELATIVE HUMDITY
12
Female DB25.
V.24 9.600-8-N-1-without flow control.
Female RJ45 on the rear panel of device.
85-264VAC / 120-300VDC
1Amp Max (RMS) @ 115VAC
47-63Hz
47W
25W
CGSM
315mm x 240mm x 43.2mm (+4mm for the legs)
2050gr (+200gr for the 19" rack wings)
-5º to 65ºC
10% to 95%
