Unpacked BCD (2-Digit Year)
In Unpacked BCD format, each digit of the time and date items occupies the low-order four bits of a
byte. The upper four bits of each byte are always zero. This format requires nine words. Values are
hexadecimal.
Parameter Block Format
1 = change or 0 = read
2 (Unpacked BCD format)
High Byte
Low Byte
year
month
day of month
hours
minutes
seconds
day of week
Unpacked BCD (4-Digit Year)
In Unpacked BCD format, each digit of the time and date items occupies the low-order four bits of a
byte. The upper four bits of each byte are always zero. This format requires nine words. Values are
hexadecimal.
Parameter Block Format
1 = change or 0 = read
82h (Unpacked 4-digit BCD format)
High Byte
Low Byte
year
month
day of month
hours
minutes
seconds
day of week
GFK-2950C
Address
Example
(Thurs., Dec. 8, 2002, at 9:34:57 a.m.)
Address
0h
Address+1
2h
High Byte
Address+2
00h
Address+3
01h
Address+4
02h
Address+5
00h
Address+6
03h
Address+7
05h
Address+8
00h
Address
Example
(Thurs., Dec. 8, 2002, at 9:34:57 a.m.)
Address
0h
Address+1
82h
High Byte
Address+2
00h
Address+3
01h
Address+4
00h
Address+5
00h
Address+6
03h
Address+7
05h
Address+8
00h
February 2018
Chapter 6. Service Request Function
Low Byte
02h
02h
08h
09h
04h
07h
05h
Low Byte
02h
02h
08h
09h
04h
07h
05h
