Commissioning

5.3 Local Control Panel Operation

5.3.1 Local Control Panel
The local control panel (LCP) is the combined display and
keypad on the front of the unit.
The LCP has several user functions:
•
Start, stop, and control speed when in local
5 5
control
•
Display operational data, status, warnings and
cautions
•
Programming adjustable frequency drive
functions
•
Manually reset the adjustable frequency drive
after a fault when auto-reset is inactive
NOTICE!
For commissioning via PC, install MCT 10 Set-up
Software. The software is available for download (basic
version) or for ordering (advanced version, order number
130B1000). For more information and downloads, see
www.danfoss.com/BusinessAreas/DrivesSolutions/Software
+MCT10/MCT10+Downloads.htm.

5.3.2 LCP Layout

The LCP is divided into four functional groups (see
Figure 5.1).
A. Display area
B. Display menu keys
C. Navigation keys and LEDs
D. Operation keys and reset
24
Instruction Manual
A. Display Area
The display area is activated when the adjustable
frequency drive receives power from AC line voltage, a DC
bus terminal, or an external 24 V DC supply.
The information displayed on the LCP can be customized
for user application. Select options in the Quick Menu
Q3-13 Display Settings.
Callout
1
2
3
4
5
Danfoss A/S © Rev. 2014-04-10 All rights reserved.
1
Status
0.00 A
0.0 %
2 0.0Hz
A
2605 kWh
4
O Remote Stop
6
Quick
Status
B
Menu
7
10 C
On OK
15
Warn.
16
Alarm
17
Hand
D
O
on
18 19
Figure 5.1 Local Control Panel (LCP)
Display Parameter number
1.1 0-20
1.2 0-21
1.3 0-22
2 0-23
3 0-24
Table 5.1 Legend to Figure 5.1, Display Area
3
1(1)
0.00 kW
5
9
Main Alarm
Menu Log
8
11
12
13
Auto
Reset
on
14
20 21
Default setting
Reference %
Motor current
Power [kW]
Frequency
kWh counter
