Specifications

8.6 Control Input/Output and Control Data

Digital inputs
Programmable digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic'0' PNP
Voltage level, logic'1' PNP
Voltage level, logic '0' NPN
Voltage level, logic '1' NPN
Maximum voltage on input
Pulse frequency ranges
(Duty cycle) Min. pulse width
Input resistance, R
Safe Torque Off Terminal 37
Voltage level
Voltage level, logic'0' PNP
8 8
Voltage level, logic'1' PNP
Maximum voltage on input
Typical input current at 24 V
Typical input current at 20 V
Input capacitance
All digital inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
1) Terminals 27 and 29 can also be programmed as output.
2)
Except Safe Torque Off input Terminal 37.
3)
See chapter 4.8 Control Wiring for further information about terminal 37 and Safe Torque Off.
4)
When using a contactor with a DC coil inside in combination with Safe Torque Off, it is important to make a return way for
the current from the coil when turning it off. This can be done by using a freewheel diode (or, alternatively, a 30 or 50 V MOV for
quicker response time) across the coil. Typical contactors can be bought with this diode.
Analog inputs
Number of analog inputs
Terminal number
Modes
Mode select
Voltage mode
Voltage level
Input resistance, R
Max. voltage
Current mode
Current level
Input resistance, R
Max. current
Resolution for analog inputs
Accuracy of analog inputs
Bandwidth
The analog inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
56
Instruction Manual
2)
2)
i
3), 4)
(Terminal 37 is fixed PNP logic)
i
i
Danfoss A/S © Rev. 2014-04-10 All rights reserved.
1) 1)
18, 19, 27 , 29 , 32, 33,
PNP or NPN
0–24 V DC
<5 V DC
>10 V DC
>19 V DC
<14 V DC
28 V DC
0–110 kHz
4.5 ms
Approx. 4 kΩ
0–24 V DC
<4 V DC
>20 V DC
28 V DC
50 mA rms
60 mA rms
400 nF
53, 54
Voltage or current
Switch S201 and switch S202
Switch S201/switch S202 = OFF (U)
-10 to +10 V (scaleable)
Approx. 10 kΩ
±20 V
Switch S201/switch S202 = ON (I)
0/4 to 20 mA (scaleable)
Approx. 200 Ω
30 mA
10 bit (+ sign)
Max. error 0.5% of full scale
100 Hz
MG16E322
1)
4 (6)
2
