Danfoss FC 103 Instruction Manual page 67

Specifications
Power SIBA Littel fuse
[kW] Type RK1 Type RK1
1.1 5017906-010 KLN-R-10
1.5 5017906-016 KLN-R-15
2.2 5017906-020 KLN-R-20
3.0 5017906-025 KLN-R-25
3.7 5012406-032 KLN-R-30
5.5/7.5 5014006-050 KLN-R-50
11 5014006-063 KLN-R-60
15 5014006-080 KLN-R-80
18.5-22 2028220-125 KLN-R-125
30 2028220-150 KLN-R-150
37 2028220-200 KLN-R-200
45 2028220-250 KLN-R-250
Table 8.13 3x200-240 V, Enclosure Types A, B and C
1)
KTS-fuses from Bussmann may substitute KTN for 240 V frequency converters.
2) FWH-fuses from Bussmann may substitute FWX for 240 V frequency converters.
3)
A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V frequency converters.
4) A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V frequency converters.
3x380-480 V
Power Bussmann
[kW] Type RK1
1.1 KTS-R-6
1.5-2.2 KTS-R-10
3 KTS-R-15
4 KTS-R-20
5.5 KTS-R-25
7.5 KTS-R-30
11/15 KTS-R-40
18 KTS-R-50
22 KTS-R-60
30 KTS-R-80
37 KTS-R-100
45 KTS-R-125
55 KTS-R-150
75 KTS-R-200
90 KTS-R-250
Table 8.14 3x380-480 V, Enclosure Types A, B and C
MG16E322
Instruction Manual
Recommended max. fuse
Ferraz-
Ferraz-
Shawmut Shawmut
Type CC
Type RK1
ATM-R-10 A2K-10-R
ATM-R-15 A2K-15-R
ATM-R-20 A2K-20-R
ATM-R-25 A2K-25-R
ATM-R-30 A2K-30-R
- A2K-50-R
- A2K-60-R
- A2K-80-R
- A2K-125-R
- A2K-150-R
- A2K-200-R
- A2K-250-R
Recommended max. fuse
Bussmann Bussmann
Type J Type T
JKS-6 JJS-6
JKS-10 JJS-10
JKS-15 JJS-15
JKS-20 JJS-20
JKS-25 JJS-25
JKS-30 JJS-30
JKS-40 JJS-40
JKS-50 JJS-50
JKS-60 JJS-60
JKS-80 JJS-80
JKS-100 JJS-100
JKS-125 JJS-125
JKS-150 JJS-150
JKS-200 JJS-200
JKS-250 JJS-250
Danfoss A/S © Rev. 2014-04-10 All rights reserved.
Bussmann
Littel fuse
Type JFHR2 2) JFHR2
3)
FWX-10 -
FWX-15 -
FWX-20 -
FWX-25 -
FWX-30 -
FWX-50 -
FWX-60 -
FWX-80 -
FWX-125 -
FWX-150 L25S-150
FWX-200 L25S-200
FWX-250 L25S-250
Bussmann Bussmann
Type CC Type CC
FNQ-R-6 KTK-R-6
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
-
-
-
-
-
-
-
-
-
Ferraz-
Ferraz-
Shawmut
Shawmut J
4)
JFHR2
- HSJ-10
- HSJ-15
- HSJ-20
- HSJ-25
- HSJ-30
- HSJ-50
- HSJ-60
- HSJ-80
- HSJ-125
A25X-150 HSJ-150
A25X-200 HSJ-200
A25X-250 HSJ-250
Bussmann
Type CC
LP-CC-6
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
- -
- -
- -
- -
- -
- -
- -
- -
- -
