Specifications

8.3 Motor Output and Motor Data

Motor output (U, V, W)
Output voltage
Output frequency (1.1–90 kW)
Switching on output
Ramp times
1)
As of software version 1.10, the output frequency of the adjustable frequency drive is limited to 590 Hz. Contact local Danfoss
partner for further information.
Torque characteristics
Starting torque (Constant torque)
Starting torque
Overload torque (Constant torque)
1) Percentage relates to the nominal torque.

8.4 Ambient Conditions

Environment
IP rating
Vibration test
Max. relative humidity
Aggressive environment (IEC 60068-2-43) H
Ambient temperature 3)
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level without derating
Derating for high altitude, see special conditions in the Design Guide.
EMC standards, Emission
EMC standards, Immunity
See section on special conditions in the Design Guide.
≤ 3.7 kW (200–240 V), ≤ 7.5 kW (380–480 V)
1)
Only for
≤ 3.7 kW (200–240 V), ≤ 7.5 kW (380–480 V)
2)
As enclosure kit for
3) Derating for high ambient temperature, see special conditions in the Design Guide

8.5 Cable Specifications

Cable lengths and cross-sections for control cables
Max. motor cable length, shielded
Max. motor cable length, non-shielded
Maximum cross-section to control terminals, flexible/ rigid wire without cable end sleeves
Maximum cross-section to control terminals, flexible wire with cable end sleeves
Maximum cross-section to control terminals, flexible wire with cable end sleeves with collar
Minimum cross-section to control terminals
1) For power cables, see electrical data tables in chapter 8.1 Electrical Data.
MG16E322
Instruction Manual
IP20
5%–93% (IEC 721-3-3; Class 3K3 (non-condensing) during operation
S test
2
Max. 122°F [50°C] (24-hour average maximum 113°F [45°C])
1)
Danfoss A/S © Rev. 2014-04-10 All rights reserved.
0–100% of supply voltage
maximum 110% for 1 min.
maximum 135% up to 0.5 s
maximum 110% for 1 min.
1) /Chassis, IP21 2) /Type 1, IP55/Type 12, IP66/Type 4X
-13°–+149°/158°F [-25°–+65°/70°°C]
1)
0–590 Hz
Unlimited
1–3600 s
1)
1)
1)
8
1.0 g
class Kd
32°F [0°C]
14°F [-10°C]
3300 ft [1000 m]
EN 61800-3
EN 61800-3
500 ft [150 m]
1000 ft [300 m]
2
1.5 mm /16 AWG
2
1 mm /18 AWG
0.5 mm 2 /20 AWG
2
0.25 mm /24 AWG
55
