Appendix
9 Appendix
9.1 Symbols, Abbreviations and Conventions
AC
AEO
AWG
AMA
°C
DC
EMC
ETR
FC
LCP
MCT
IP
I
M,N
f
M,N
P
M,N
U
M,N
PM Motor
PELV
PCB
PWM
I
LIM
I
INV
RPM
Regen
n
s
T
LIM
I
VLT,MAX
I
VLT,N
Table 9.1 Symbols and Abbreviations
Conventions
Numbered lists indicate procedures.
Bullet lists indicate other information and description of figures.
Italicized text indicates
•
cross reference
•
link
•
parameter name
9.2 Parameter Menu Structure
MG16E322
Instruction Manual
Alternating Current
Automatic Energy Optimization
American Wire Gauge
Automatic Motor Adaptation
Degrees Celsius
Direct Current
Electro Magnetic Compatibility
Electronic Thermal Relay
Adjustable Frequency Drive
Local Control Panel
Motion Control Tool
Ingress Protection
Nominal Motor Current
Nominal Motor Frequency
Nominal Motor Power
Nominal Motor Voltage
Permanent Magnet Motor
Protective Extra Low Voltage
Printed Circuit Board
Pulse Width Modulated
Current Limit
Rated Inverter Output Current
Revolutions Per Minute
Regenerative Terminals
Synchronous Motor Speed
Torque Limit
The Maximum Output Current
The Rated Output Current Supplied by the Adjustable Frequency Drive
