Electrical Installation

4.8.1 Control Terminal Types

Figure 4.7 and Figure 4.8 show the removable adjustable
frequency drive connectors. Terminal functions and default
settings are summarized in Table 4.2.
Figure 4.7 Control Terminal Locations
1
12 13 18 19 27 29 32 33 20 37
2
3
61 68 69
39 42 50 53 54 55
Figure 4.8 Terminal Numbers
Connector 1 provides four programmable digital
inputs terminals, two additional digital terminals
programmable as either input or output, a 24 V
DC terminal supply voltage, and a common for
optional customer supplied 24 V DC voltage
Connector 2 terminals (+)68 and (-)69 are for an
RS-485 serial communication connection
Connector 3 provides two analog inputs, one
analog output, 10 V DC supply voltage, and
commons for the inputs and output
Connector 4 is a USB port available for use with
the MCT 10 Set-up Software
MG16E322
Instruction Manual
Terminal
12, 13
18
19
32
4
33
1
27
29
20
37
39
42
50
53
54
55
61
Danfoss A/S © Rev. 2014-04-10 All rights reserved.
Digital Inputs/Outputs
Parameter
Default
Description
setting
-
+24 V DC
24 V DC supply
voltage. Maximum
output current is
200 mA total for all
24 V loads. Usable for
digital inputs and
external transducers.
5-10
[8] Start
5-11
[10] Reversing
5-14
[39] Day/Night
Digital inputs.
Control
5-15
[0] No
operation
5-12
[2] Coast
Selectable for either
inverse
digital input or
output. Default setting
5-13
[0] No
operation
is input.
-
Common for digital
inputs and 0 V
potential for 24 V
supply.
-
Safe Torque
(Optional) Safe input.
Off (STO)
Used for STO
Analog Inputs/Outputs
-
Common for analog
output.
6-50
[100] Output
Programmable analog
frequency
output. The analog
signal is 0–20 mA or
4–20 mA at a
maximum of 500 Ω.
-
+10 V DC
10 V DC analog
supply voltage. 15 mA
maximum commonly
used for potenti-
ometer or thermistor.
6-1*
Reference
Analog input.
Selectable for voltage
6-2*
Feedback
or current. Switches
A53 and A54 select
mA or V.
-
Common for analog
input.
Serial Communication
-
Integrated RC filter for
cable shield. ONLY for
connecting the shield
when experiencing
EMC problems.
4
4
19
