Pre-assembly C: Roll paper supply module

Reassembly
Part name
step
1 frame, paper supply unit× 1
Roll paper holder unit
2 Collar, screw holder
C.B (M4 × × × × 16)
3
S. washer-2, 4
Plate, rotation stopper
assembly
P. washer (4.3 × × × × 0.8 × × × × 8) × 1
4
H. nut (4)
★
5 Collar, screw holder
C.B (M4 × × × × 16)
S. washer-2, 4
Plate, rotation stopper
assembly
P. washer (4.3 × × × × 0.8 × × × × 8)
H. nut (4)
★
6
roll paper holder unit
square hole
frame, paper
supply unit
Rev. A
Place the frame, paper supply unit on the roll paper holder unit aligning
× 1
the hole positions.
× 1
Attach the collar, screw holder to the screw hole on the frame from
outside.
× 1
Attach a S. washer and the plate rotation stopper assembly to a C. B (M4
× 1
x 16) screw, and fit it into the collar, screw holder on the frame from
outside so that the bent part on the plate, rotation stopper assembly is fit
× 1
in the square hole on the frame.
Attach a P. washer (4.3 x 0.8 x 8) from inside of the frame, then secure it
× 1
with an H. nut (4).
< Check >
Tightening torque: 441 to 539 mN•m {4.5 to 5.5 kg•cm}
× 1
Perform the same steps for the other side.
× 1
× 1
× 1
× 1
× 1
< Check >
Tightening torque: 441 to 539 mN•m {4.5 to 5.5 kg•cm}
Lubricate the H.nut (4) and the screw part with screw lock.
EU-T432 Technical Manual
Assembly procedure
square hole
plate, rotation stopper
assembly
collar, screw holder
P. washer (4.3 × 0.8 × 8)
H. nut (4)
Assembly and Disassembly 6-39
C.B (M4 × 16)
S. washer-2, 4
