Creating a Scene

all the elements on to "harmonize" the scene. Press the
button again and all elements of the scene will turn off.
Use one or more of the controllers shown here to
program scenes to be activated by specific buttons on
the controller(s).
<SCENE SELECTION> buttons <SCENE SELECTION> buttons
Hand-Held with Base Hand-Held with Base
1. If using a Hand-Held, make sure the lights under the
Hand-Held's buttons are lit. If they are not lit, press
any button to wake the Hand-Held from battery-
saving sleep mode.
2. Press and hold (for approximately 10 seconds) the
<SCENE SELECTION>
scene. The Status Light on the device will pulse
once slowly with a blue light. This indicates that the
button is in "learning" mode.
NOTE: Scene "learning" mode will time-out after
5 minutes from the last button press and save the
scene.
3. Go around your home and make a change in the
status of each device you want to include in the
scene. For example, turn a room light on or off, set a
dimmer to a desired level, etc. To include an InTouch
electric outlet (e.g., where you have plugged in a
lamp), press the button on the outlet.
To include other Z-Wave devices in the scene (i.e.,
Intermatic HomeSettings devices or other brands),
turn them ON or OFF from their existing state. The
system will turn them back to their original state
Copyright © 2006 Intermatic, Inc.
STATUS STATUS
LIGHT LIGHT
<ENTER> <ENTER>
button button
In-Wall Scene/Group Controller In-Wall Scene/Group Controller
button you want to control the
