NOTE: On InTouch devices that have this feature,
the status light will stop blinking BLUE and/or RED
to indicate that the device has been added to the
network.
Additional Considerations:
• If the device doesn't have a button (for example,
a simple on-off switch), press the rocker switch
on the device.
• If the device is the In-Wall
Scene/Group Controller,
press and hold (for 4+
seconds) the
on the device. The Status
Light on the Hand-Held will:
- Blink BLUE once if the
procedure is successful.
- Blink RED once if the procedure failed. If this
happens, the In-Wall Scene/Group Controller
must be
network.
• If the device is the In-Wall Master Controller:
NOTE: It is best to add this device to the network
last.
Begin at the InTouch
Home Screen as
shown.
a. Press
<ENTER>
screen displays the
Main Menu.
b. Scroll with the
<UP/DOWN>
arrows to select
Setup, then press
<ENTER>
screen displays system setup options.
Providing a brighter solution.™
Setting Up Your Network
button
<HOME>
and then
EXCLUDED
WIRELESS CONTROLS WIRELESS CONTROLS
. The
Setup Setup
Setup Setup
. The
<HOME> <HOME>
button button
RE-INCLUDED
11:25 11:25
TM TM
My Scenes My Scenes
My Events My Events
Setup Home Setup Home
Set Time Set Time
Setup Network Setup Network
1
STATUS STATUS
LIGHT LIGHT
to the
a a
11:25a 11:25a
11:25a 11:25a
