Side-by-side ESMs in DE1600 drive shelves and DE5600 drive shelves
1.
ESM A
2.
SAS In - Port 1
3.
SAS In - Port 2
4.
SAS Out (Expansion) Port
5.
ESM B
Side-by-side ESMs in DE212C drive shelves and DE224C drive shelves
1.
2.
3.
4.
5.
ESM A
SAS Port 1
SAS Port 2
SAS Port 3
SAS Port 4
Drive shelf or drive tray cabling | 75
