Quantum StorNext QD7000 Hardware Manual

Hide thumbs Also See for StorNext QD7000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual, Manual
Hardware Cabling Guide
StorNext QD7000
Firmware 8.30.xx.xx
6-68574-01 Rev A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the StorNext QD7000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Quantum StorNext QD7000

Summary of Contents for Quantum StorNext QD7000

  • Page 1 Hardware Cabling Guide StorNext QD7000 Firmware 8.30.xx.xx 6-68574-01 Rev A...
  • Page 2 Artico, Be Certain (and the Q brackets design), DLT, DXi, DXi Accent, DXi V1000, DXi V2000, DXi V4000, DXiV-Series, FlexTier, Lattus, the Q logo, the Q Quantum logo, Q-Cloud, Quantum (and the Q brackets design), the Quantum logo, Quantum Be Certain...
  • Page 3 Titan RAID controller, only). Refer to the NetApp to Quantum Naming Decoder section for additional information. This section provides the following information: • Audience • Prerequisites • NetApp to Quantum Naming Decoder • Product Safety Statements • Contacts • Comments • Quantum Global Services Audience This manual is intended for storage customers and technicians.
  • Page 4 Product Quantum-Storage Description Controller-Drive Tray Base System Quantum uses Base System when referring to a drive tray with the RAID controllers. Drive Tray Expansion Unit Quantum uses Expansion Unit when referring to a drive tray with the environmental services modules (ESMs).
  • Page 5 Preface E-Series NetApp Product Quantum-Storage Description E5560 or E5660 Quantum StorNext QD7000 (DE6600 4U drive enclosure with E5500 or E5600 RAID controllers) E5460 Quantum StorNext QD6000 (DE6600 4U drive enclosure with E5400 RAID controllers) E5424 Quantum StorNext QS2400 (DE5600 24-drive 2U...
  • Page 6 Preface Product Safety Quantum will not be held liable for damage arising from unauthorized Statements use of the product. The user assumes all risk in this aspect. This unit is engineered and manufactured to meet all safety and regulatory requirements. Be aware that improper use may result in bodily injury, damage to the equipment, or interference with other equipment.
  • Page 7 Preface Contacts For information about contacting Quantum, including Quantum office locations, go to: http://www.quantum.com/aboutus/contactus/index.aspx Comments To provide comments or feedback about this document, or about other Quantum technical publications, send e-mail to: doc-comments@quantum.com Hardware Cabling Guide...
  • Page 8 Online Service accounts are free from Quantum. That account can also be used to access Quantum’s Knowledge Base, a comprehensive repository of product support information. Get started at: http://www.quantum.com/customercenter/ For further assistance, or if training is desired, contact the Quantum Customer Support Center: North America 1-800-284-5101 (toll free) +1-720-249-5700...
  • Page 9 E-Series Hardware Cabling Guide December 2016 | 215-11208_B0 doccomments@netapp.com...

  • Page 11: Table Of Contents

    Table of Contents | 3 Contents Deciding whether to use this guide ............. 6 Cabling concepts and best practices ............7 Cabling concepts ......................7 Fabric (switched) topologies compared to direct-attach topologies ....7 Trays and shelves .................... 7 Host channels and drive channels ..............8 Host ports and drive ports ................
  • Page 12 4 | Hardware Cabling Guide Component locations on the E2800 controller shelves ..........33 Component locations on the E2700 controller-drive trays ........37 Component locations on the E2600 controller-drive trays ........45 Component locations on the DE6600 drive shelf (drive tray) ........53 Component locations on the DE212C drive shelf and the DE224C drive shelf ..
  • Page 13 Table of Contents | 5 Drive tray cabling topologies for the E2600 controller-drive trays ......115 Drive channel redundancy for the E2612 and E2624 controller-drive trays ....................... 116 Drive tray cabling topologies for the E2612 controller-drive tray and the E2624 controller-drive tray ..............118 Drive cabling topologies for the E2660 controller-drive tray with DE6600 drive trays ................

  • Page 14: Deciding Whether To Use This Guide

    Deciding whether to use this guide This guide contains conceptual information and best practices for cabling your storage array. It includes the following types of procedures: • Host cabling • Drive cabling • Ethernet cabling for a management station • Cabling to support mirroring features This guide is intended for a hardware installer or system administrator who is installing or expanding a storage array, or cabling to support mirroring features.

  • Page 15: Cabling Concepts And Best Practices

    Cabling concepts and best practices This chapter describes cabling concepts, best practices, and common procedures that apply generally across the specific cabling configuration that are covered in subsequent chapters. Cabling concepts Learn more about cabling concepts to help you cable your storage array. Fabric (switched) topologies compared to direct-attach topologies Fabric topologies use a switch or router, while direct-attach topologies do not.

  • Page 16: Host Channels And Drive Channels

    8 | Hardware Cabling Guide Term used for E2700 and Term used for E2800 storage Definition E5600 storage arrays, and arrays EF560 flash arrays controller canister controller canister The component in a controller- drive tray or controller shelf that includes a controller card, a battery, and–optionally–a host interface card.

  • Page 17: Host Ports And Drive Ports

    Cabling concepts and best practices | 9 Host ports and drive ports The ports are the physical connectors on the controller shelf (controller-drive tray) that, along with the cabling, enable the transfer of data. If the port communicates with the host server, it is a host port .

  • Page 18: Redundant And Non-Redundant Components

    10 | Hardware Cabling Guide For more information, see the SANtricity Power Guide for Advanced Users for your operating system. Related information SANtricity 11.30 Installing and Configuring for Linux Power Guide for Advanced Users SANtricity 11.30 Installing and Configuring for VMware Power Guide for Advanced Users SANtricity 11.30 Installing and Configuring for Windows Power Guide for Advanced Users Redundant and non-redundant components In storage area network technology, redundancy means that essential services are implemented using...

  • Page 19: Host Adapters

    Cabling concepts and best practices | 11 73136 Copper cable Passive SFP transceiver Host adapters Each connection from a host port on a controller to a host is made through a host adapter on the host. A host adapter can be a host bus adapter (HBA) for Fibre Channel or SAS connections, a host channel adapter (HCA) for InfiniBand connections, or an Ethernet adapter for iSCSI connections.

  • Page 20: Switches And Zoning

    12 | Hardware Cabling Guide required for network communication. Each Ethernet cable connection for out-of-band storage array management is made through an NIC. If your configuration requires a host Ethernet connection through an NIC, you must obtain Note: and install the required NICs. Related concepts In-band management and out-of-band management on page 12...

  • Page 21: Host Cabling For Redundancy

    Cabling concepts and best practices | 13 Host cabling for redundancy To ensure that the storage array remains accessible to the host in the event that a host channel fails, establish two physical paths from each host to the controllers, and install alternate path software on the host.

  • Page 22: Single-Controller Topologies And Dual-Controller Topologies

    14 | Hardware Cabling Guide iSCSI connections for mirroring, any one of the iSCSI ports can be used for the mirroring connection. Single-controller topologies and dual-controller topologies A controller shelf (controller-drive tray) that contains two controllers is called a duplex configuration. A controller shelf with only one controller is called a simplex configuration.
  • Page 23 Cabling concepts and best practices | 15 Controller-drive tray for the storage array When you use out-of-band management , the storage management station is connected through an Ethernet network to each of the controllers in the controller shelf or controller-drive tray. E2800 controller shelves can use out-of-band management with SANtricity System Manager.

  • Page 24: Labeling Cables

    16 | Hardware Cabling Guide Where two Ethernet ports are available on a controller, use the port labeled P1 for out-of- Note: band Ethernet connections. Reserve the second Ethernet port (labeled P2) for access by technical support. For information about how to create a redundant out-of-band topology, see Fabric out-of-band Ethernet topology on page 134.

  • Page 25: Installing An Sfp Transceiver And A Fiber-Optic Cable

    Cabling concepts and best practices | 17 Installing an SFP transceiver and a fiber-optic cable You must install SFP transceivers into each connector to which you will connect a fiber-optic cable. About this task Be aware of potential hardware risks when performing this task. Attention: Potential degraded performance –...

  • Page 26: Installing A Copper Cable With A Passive Sfp Transceiver

    18 | Hardware Cabling Guide Fiber-optic cable SFP transceiver Host interface port 4. Install the fiber-optic cable. Installing a copper cable with a passive SFP transceiver You must install a passive SFP transceiver into each connector to which you will connect a copper cable.

  • Page 27: Installing An Rj-45 Cable For Iscsi Connections

    Cabling concepts and best practices | 19 Your passive SFP transceivers might look slightly different from the one shown. The differences do not affect the performance of the SFP transceiver. 73136 Copper cable Passive SFP transceiver Note: Make sure that the passive SFP transceiver installs with an audible click. 3.

  • Page 28: Installing A Sas Cable

    20 | Hardware Cabling Guide 3. For each cable, insert one RJ-45 connector into a host interface port on the controller and the other RJ-45 connector into a port on the host’s Ethernet adapter or Ethernet switch. Installing a SAS cable You must install SAS cables to be used for drive shelf (drive tray) connections or for host connections.

  • Page 29: Component Locations

    Component locations You must make sure that you have correctly identified the cable connection for host cabling, drive shelf cabling, and Ethernet cabling. The figures included in this section identify the locations of controllers, environmental services modules or I/O modules (ESMs/IOMs), host ports, drive ports, and Ethernet ports. The figures also show port identifiers.
  • Page 30 22 | Hardware Cabling Guide E5560 controller-drive tray or E5660 controller-drive tray - front view with bezel removed Drive drawer Locate LED Service Action Required LED Over-Temperature LED Power LED Standby Power LED The following figure shows the controller-drive tray or flash array with a 12-Gb/s SAS HIC. Your controller-drive tray might have a different HIC.
  • Page 31 Component locations | 23 E5524, E5624, EF550, and EF560 controller-drive trays - front view with bezel removed End cap Standby Power LED End cap Power LED End cap Over-Temperature LED End cap Service Action Required LED End cap Locate LED Drive canister E5512 controller-drive tray and E5612 controller-drive tray - front view with bezel removed Identify LED...
  • Page 32 24 | Hardware Cabling Guide Controller canister A Drive channel port (SAS drive expansion connectors) Controller canister B Drive channel port (SAS drive expansion connectors) E5500, E5600, EF550, and EF560 controller module USB connector 11. SAS Expansion Link 2 Fault LED 1GbE management connector 1 12.
  • Page 33 Component locations | 25 Mini-SAS Port 1 Link Fault LED Mini-SAS Port 3 Link Fault LED Mini-SAS Port 1 Link Up LED Mini-SAS Port 3 Link Up LED SFF-8088 HIC connector 2 SFF-8088 HIC connector 4 Mini-SAS Port 2 Link Fault LED Mini-SAS Port 4 Link Fault LED Mini-SAS Port 2 Link Up LED Mini-SAS Port 4 Link UP LED...
  • Page 34 26 | Hardware Cabling Guide HIC Logical Link 1 Active LED HIC Physical Link 1 Active LED Serial port HIC Logical Link 2 Active LED HIC Physical Link 2 Active LED HIC QSFP channel 2 Right, rear subplate with a 56-Gb InfiniBand HIC HIC QSFP channel 1 HIC Logical Link 1 Active LED HIC Physical Link 1 Active LED...

  • Page 35: Component Locations On The E5400 Controller-Drive Trays And The Ef540 Flash Array

    Component locations | 27 HIC Link 1 Fault LED HIC Link 3 Active LED HIC Link 1 Active LED Serial port SFP+ HIC channel 2 HIC Link 4 Fault LED HIC Link 2 Fault LED HIC Link 4 Active LED HIC Link 2 Active LED SFP+ HIC channel 4 SFP+ HIC channel 3...
  • Page 36 28 | Hardware Cabling Guide E5460 controller-drive tray - rear view 9 10 1 1 12 13 14 15 17 18 19 92045-05 Fan canister 19. Mini USB connector Fan Power LED 20. Expansion Fault LED Fan Service Action Required LED 21.
  • Page 37 Component locations | 29 E5424 controller-drive tray and EF540 flash array - front view Locate LED Service Action Required LED Over-Temperature LED Power LED Standby Power LED Drive canister E5412 controller-drive tray - front view 1 2 3 98006-06 Locate LED Service Action Required LED Over-Temperature LED Power LED...
  • Page 38 30 | Hardware Cabling Guide E5424 controller-drive tray and EF540 flash array - rear view 9 10 1 1 12 14 15 50004-04 18 19 Controller A canister 13. Base host Fibre Channel SFP+ connectors Seven-segment display 14. Expansion SFF-8088 port connector HIC connector 1 15.
  • Page 39 Component locations | 31 Right, rear subplate with no HIC Mini USB connector SAS expansion Fault LED SAS expansion Active LED SAS SFF-8088 port connector Right, rear subplate with a Fibre Channel HIC Mini USB connector HIC Link 6 LED 0 SAS expansion Fault LED HIC Link 6 LED 1 SAS expansion Active LED...
  • Page 40 32 | Hardware Cabling Guide Right, rear subplate with a SAS HIC 1. SAS expansion SFF-8088 port connector 1 SAS Host SFF-8088 port connector 3 2. SAS Host Interface Port 1 Fault LED SAS Host Interface Port 3 Fault LED 3.

  • Page 41: Component Locations On The E2800 Controller Shelves

    Component locations | 33 SAS expansion Link Up LED IB HIC connector 2 SAS expansion SFF-8088 port connector IB HIC Physical Link 2 LED (Green) IB HIC connector 1 IB HIC Logical Link 2 LED (Amber) Component locations on the E2800 controller shelves The E2812 controller shelf has twelve 3.5 in.
  • Page 42 34 | Hardware Cabling Guide E2860 controller shelf front bezel Power Attention Locate E2812 or E2824 controller shelf – duplex configuration (rear view) E2812 or E2824 controller shelf – simplex configuration (rear view)
  • Page 43 Component locations | 35 E2860 controller shelf (rear view) E2800 controller LEDs Cache Active Locate Attention Activity Ethernet Activity Ethernet Link Speed Expansion Port Link Status (SAS expansion port) Expansion Port Attention (SAS expansion port) Host Port Link Status (baseboard host port) Host Port Attention (baseboard host port) Host Port Link Status (HIC host port) Host Port Attention (HIC host port)
  • Page 44 36 | Hardware Cabling Guide E2800 controller with RJ-45 baseboard ports and no host interface card Two baseboard host ports – 10 Gb/s iSCSI E2800 controller with RJ-45 baseboard ports and a dual-port RJ-45 host interface card Two baseboard host ports –10 Gb/s iSCSI Two HIC ports –10 Gb/s iSCSI E2800 controller with SFP baseboard ports and no host interface card Two baseboard host ports –16 Gb/s FC or 10 Gb/s iSCSI...

  • Page 45: Component Locations On The E2700 Controller-Drive Trays

    Component locations | 37 Two HIC ports – 12 Gb/s SAS E2800 controller with SFP baseboard ports and a quad-port SAS host interface card Two baseboard host ports –16 Gb/s FC or 10 Gb/s iSCSI Four HIC ports –12 Gb/s SAS E2800 controller with SFP baseboard ports and a dual-port SFP (FC or iSCSI) host interface card Two baseboard host ports –16 Gb/s FC or 10 Gb/s iSCSI...
  • Page 46 38 | Hardware Cabling Guide two different controller configurations: simplex (one controller) and duplex (two controllers). The E2760 controller-drive tray is available only in the duplex configuration. Keep these points in mind when you compare the figures in this section to your hardware: •...
  • Page 47 Component locations | 39 Locate LED Drive Canister E2712 controller-drive tray or E2724 controller-drive tray duplex configuration - rear view Battery Charging LED 15. Host Link 1 Active LED Battery Service Action Required LED 16. Base Host SFF-8644 Connector 1 Controller A Service Action Allowed LED 17.
  • Page 48 40 | Hardware Cabling Guide E2712 controller-drive tray or E2724 controller-drive tray simplex configuration - rear view Controller A Canister Unused Controller B Slot Seven-Segment Display Power-Fan A Canister Host Interface Card Connector 1 Standby Power LED Host Interface Card Connector 2 Power-Fan DC Power LED Expansion Fault LED Power-Fan Service Action Allowed LED...
  • Page 49 Component locations | 41 E2760 controller-drive tray duplex configuration - rear view Fan Canister 19. Expansion Fault LED Fan Power LED 20. Expansion Active LED Fan Service Action Required LED 21. Expansion SFF-8644 Port Connector Fan Service Action Allowed LED 22.
  • Page 50 42 | Hardware Cabling Guide E2700 right, rear subplate with no host interface card Expansion Fault LED Expansion Active LED Expansion SFF-8644 Port Connector E2700 right, rear subplate with a dual port SAS host interface card Host Interface Link 3 Fault LED SFF-8644 Host Interface Connector 4 Host Interface Link 3 Active LED Expansion Fault LED...
  • Page 51 Component locations | 43 Host Interface Card Link 4 Active LED E2700 right, rear subplate with a quad port SAS host interface card Host Interface Link 3 Fault LED SFF-8644 Host Interface Connector 4 Host Interface Link 3 Active LED Expansion Fault LED SFF-8644 Host Interface Connector 3 Expansion Active LED...
  • Page 52 44 | Hardware Cabling Guide Host Interface Link 3 Up LED FC Host Interface Connector 4 Host Interface Link 3 Active LED Expansion Fault LED FC Host Interface Connector 3 Expansion Active LED Host Interface Link 4 Up LED Expansion SFF-8644 Port Connector Host Interface Card Link 4 Active LED For each pair of LEDs associated with a host connector (1 and 2, 4 and 5), the following table shows what different lighting patterns indicate.

  • Page 53: Component Locations On The E2600 Controller-Drive Trays

    Component locations | 45 Left (green) on Left (green) off Left (green) on Left (green) off Right (yellow) on Right (yellow) on Right (yellow) off Right (yellow) off link down link up, 8Gb/s link up, 4Gb/s link up, 16Gb/s iSCSI 1.
  • Page 54 46 | Hardware Cabling Guide the handle and the host port might make it difficult to remove a cable that is attached to the host port. If this problem occurs, use a flat-blade screwdriver to compress the release on the cable connector.
  • Page 55 Component locations | 47 E2600 controller-drive tray duplex configuration - rear view Controller A 15. Host SFF-8088 Connector 1 Battery Charging LED 16. Host Link 1 Fault LED Battery Service Action Required LED 17. Host Link 1 Active LED Controller A Service Action Allowed LED 18.
  • Page 56 48 | Hardware Cabling Guide E2600 controller-drive tray simplex configuration - rear view Controller A Canister Unused Controller B Slot Seven-Segment Display Power-Fan A Canister Host Interface Card Connector 1 Standby Power LED Host Interface Card Connector 2 Power-Fan DC Power LED Expansion Fault LED Power-Fan Service Action Allowed LED Expansion Active LED...
  • Page 57 Component locations | 49 E2660 controller drive tray - rear view Fan Canister Controller A Canister Fan Power LED Expansion Fault LED Fan Service Action Required LED Expansion Active LED Fan Service Action Allowed LED Expansion SFF-8088 Port Connector Serial Connector Second Seven-Segment Display Ethernet Link 1 Active LED First Seven-Segment Display...
  • Page 58 50 | Hardware Cabling Guide E2600 right, rear subplate with no host interface card Drive Expansion 98019-04 Expansion Fault LED Expansion Active LED Expansion SFF-8088 Port Connector E2600 right, rear subplate with a SAS host interface card Drive Expansion 98019-03 Host Interface Link 3 Fault LED SFF-8088 Host Interface Connector 4 Host Interface Link 3 Active LED...
  • Page 59 Component locations | 51 E2600 right, rear subplate with an FC host interface card 2 3 4 9 10 1 1 12 13 14 15 Drive Expansion 98019-01 Host Interface Link 3 Up LED FC Host Interface Connector 5 Host Interface Link 3 Active LED Host Interface Card Link 6 Up LED FC Host Interface Connector 3 Host Interface Card Link 6 Active LED...
  • Page 60 52 | Hardware Cabling Guide E2600 right, rear subplate with a 1-Gb/s iSCSI host interface card 2 3 4 14 15 8 9 10 1 1 12 Ch 3 Ch 4 Ch 5 Ch 6 iSCSI Host Drive Card Expansion 98019-02 Host Interface Link 3 Up LED iSCSI Host Interface Connector 5...

  • Page 61: Component Locations On The De6600 Drive Shelf (Drive Tray)

    Component locations | 53 iSCSI Host Interface Connector 3 iSCSI Host Interface Connector 4 Host Interface Link 3 Up LED Expansion Fault LED Host Interface Link 3 Active LED Expansion Active LED Host Interface Link 4 Up LED Expansion SFF-8088 Port Connector Host Interface Card Link 4 Active LED Component locations on the DE6600 drive shelf (drive tray) DE6600 drive shelf - front view with the bezel in place...

  • Page 62: Component Locations On The De212C Drive Shelf And The De224C Drive Shelf

    54 | Hardware Cabling Guide DE6600 drive shelf - rear view ESM A ESM B SAS In connectors Expansion connectors Component locations on the DE212C drive shelf and the DE224C drive shelf The DE212C drive shelf has twelve 3.5 in. drive bays. The DE224C drive shelf has twenty-four 2.5 in.

  • Page 63: Component Locations On The De460C Drive Shelf

    Component locations | 55 DE212C or DE224C drive shelf - IOM LEDs SAS port Attention IOM Attention Locate SAS port Link Status Component locations on the DE460C drive shelf The DE460C drive shelf has five drawers. Each drawer has twelve 2.5 in. drive bays. The front view and the location of LEDs on the operator display panel are the same as for the E2860 controller shelves.

  • Page 64: Component Locations On The De1600 Drive Shelf (Drive Tray) And The De5600 Drive Shelf (Drive Tray)

    56 | Hardware Cabling Guide SAS port Attention IOM Attention Locate SAS port Link Status Component locations on the DE1600 drive shelf (drive tray) and the DE5600 drive shelf (drive tray) The DE1600 drive shelf has twelve 3.5 in. drive bays. The DE5600 drive shelf has twenty-four 2.5 in. drive bays.
  • Page 65 Component locations | 57 DE1600 drive shelf or DE5600 drive shelf - rear view ESM A canister Expansion port SFF-8088 connector SAS In connector 1 Power-fan canister SAS In connector 2 Power connector Seven-segment display indicators Power switch Serial connector ESM B canister Ethernet connector...

  • Page 66: Host Cabling

    Host cabling This chapter provides examples of cabling topologies between one or more hosts and a controller shelf or controller-drive tray. Direct-attach topologies, fabric topologies, and mixed topologies are addressed. You have several options for cabling between one or more hosts and a controller shelf or controller- drive tray.
  • Page 67 Host cabling | 59 Cable Data rate and Number of Connector Type Length protocol connectors 12 Gb/s SAS MiniSAS-HD passive copper 1-5m MiniSAS-HD active copper 8-15m MiniSAS-HD optical 5-100m Fan-out cable type passive copper Fan-out cable type passive copper 6 Gb/s SAS MiniSAS passive copper 1-10m...
  • Page 68 60 | Hardware Cabling Guide HICs and Base Ports Cable Data rate and Number of Connector Type Length protocol connectors 6 Gb/s SAS MiniSAS passive copper 1-10m MiniSAS active copper 5-20m Fan-out cable type passive copper 40 Gb/s InfiniBand QSFP+ passive copper 1-5m QSFP+...
  • Page 69 Host cabling | 61 HICs and base ports Cable Data rate and Number Connector Type Length protocol and type of connectors 10 Gb/s iSCSI or 4 HIC SFP+ OM2 optical 2,3,5,10,25 optical ports 1 Gb/s iSCSI SFP+ OM3 optical 50-300m Twin-Ax (DAC) passive copper 2-7m...
  • Page 70 62 | Hardware Cabling Guide Cable Data rate and Number of Connector Type Length protocol connectors 16 Gb/s Fibre SFP+ OM2 SW optical 2,3,5,10,25 Channel SFP+ OM3 SW optical 50-150m SFP+ OS2 LW optical 50-300m SFP+ OM2 SW optical 2,3,5,10,25 SFP+ OM3 SW optical 50-150m...
  • Page 71 Host cabling | 63 HICs and base ports Cable Data rate and Number of Connector Type Length protocol connectors Base Ports: MiniSAS passive copper 1-5m 6 Gb/s SAS Fan-out cable type passive copper 6 Gb/s SAS MiniSAS passive copper 1-5m Fan-out cable type passive copper 8 Gb/s Fibre...

  • Page 72: Maximum Number Of Host Connections

    64 | Hardware Cabling Guide HIC port Before the conversion to After the conversion to split mode split mode 16 Gb/s Fibre Channel or 10 Gb/s iSCSI 10 Gb/s iSCSI 16 Gb/s Fibre Channel or 10 Gb/s iSCSI 10 Gb/s iSCSI 16 Gb/s Fibre Channel or 16 Gb/s Fibre Channel 10 Gb/s iSCSI...

  • Page 73: Direct-Attach Topologies

    Host cabling | 65 Possible loss of data access – Do not use a combination of HBAs from different Attention: vendors in the same storage area network (SAN). For the HBAs to perform correctly, use only HBAs from one manufacturer in a SAN. Direct-attach topologies This section describes topologies that do not use switches to connect hosts to your storage array.
  • Page 74 66 | Hardware Cabling Guide The following figure shows an example of a direct-attach topology with two hosts and a duplex controller shelf. In this example, the hosts/servers must be clustered to guarantee redundancy. Note: Host/Server Host/Server HBA 1 HBA 2 HBA 1 HBA 2 Host...

  • Page 75: One Host With Direct Sas Connections To Four Controller Shelves Or Controller-Drive Trays

    Host cabling | 67 Host/Server HBA 1 Host Host Port 1 Port 2 Controller A 74099 The following table lists the redundant and non-redundant components in a direct-attached configuration with one host and a simplex controller shelf. Component Redundancy Host/server Non-redundant HBA, HCA, or iSCSI Ethernet adapter Non-redundant...

  • Page 76: Switch Topologies

    68 | Hardware Cabling Guide The following table lists the redundant and non-redundant components in a direct-attached configuration with one host and four duplex controller-drive trays. Component Redundant Non-redundant Host/server (see note) Non-redundant HIC (SAS) Redundant Host-to-controller cables Redundant Controllers Redundant Switch topologies This section describes topologies that use switches to connect hosts to your storage array.
  • Page 77 Host cabling | 69 Host/Server HBA 1 HBA 2 Host Host Host Host Port 1 Port 2 Port 1 Port 2 Controller A Controller B 74102 The following table lists the redundant and non-redundant components in a switched configuration with one host and a controller shelf. Component Redundant Host/server...
  • Page 78 70 | Hardware Cabling Guide The following table lists the redundant and non-redundant components in a switched configuration with two hosts and a controller shelf. Component Redundancy Host/server (see note) Redundant Host adapter Redundant Host-to-controller cable Redundant Switch Use two switches for full redundancy. A single zoned switch is not redundant.

  • Page 79: Mixed Topologies

    Host cabling | 71 The following table lists the redundant and non-redundant components in a switched configuration with four hosts, a controller shelf, and two zoned switches. Component Redundancy Host/server (see note) Redundant Host adapter Redundant Host-to-controller cable Redundant Switch Redundant Controller Redundant...
  • Page 80 72 | Hardware Cabling Guide Host/Server 1 Host/Server 2 Host/Server 3 HBA 1 HBA 2 HBA 1 HBA 2 HBA 1 HBA 2 Host Host Host Host Port 1 Port 1 Port 2 Port 2 Controller A Controller B 74104 The following table lists the redundant and non-redundant components in a mixed configuration with three hosts and a controller shelf.

  • Page 81: Drive Shelf Or Drive Tray Cabling

    Drive shelf or drive tray cabling A controller shelf (controller-drive tray) along with any drive shelves (drive trays) that are attached to it, comprise a storage array. When a storage array includes drive shelves, each controller in the controller shelf is connected to an environmental services module (ESM) for SAS-2 connections, or to an I/O module (IOM) for SAS-3 connections in a drive shelf.

  • Page 82: Esm Module And Iom Module Arrangements

    74 | Hardware Cabling Guide Controller DE1600 and DE212C, DE6600 DE1600, DE5600, shelf or DE5600 DE224C, and and DE6600 controller- DE460C drive tray EF540 DE5600 only. Not Supported Not Supported Not Supported Solid state drives (SSDs) only not to exceed 120 drive slots or 5 enclosures* E5500...
  • Page 83 Drive shelf or drive tray cabling | 75 Side-by-side ESMs in DE1600 drive shelves and DE5600 drive shelves ESM A SAS In - Port 1 SAS In - Port 2 SAS Out (Expansion) Port ESM B Side-by-side ESMs in DE212C drive shelves and DE224C drive shelves ESM A SAS Port 1 SAS Port 2...

  • Page 84: Drive Tray Cabling Topologies For The E5500 And E5600 Controller-Drive Trays And The Ef550 And Ef560 Flash Arrays

    76 | Hardware Cabling Guide Stacked ESMs in DE6600 drive shelves ESM A ESM B SAS In Ports SAS In Ports SAS Out (Expansion) Ports Stacked IOMs in DE460C drive shelves IOMs Drive tray cabling topologies for the E5500 and E5600 controller-drive trays and the EF550 and EF560 flash arrays This section provides examples of drive tray cabling topologies for the E5600 (E5612, E5624, E5660) controller-drive trays, the EF560 flash array, the E5500 controller-drive trays (E5512, E5524,...

  • Page 85: Drive Channel Redundancy For The E5500 Controller Drive Trays, E5600 Controller Drive Trays, Ef550 Flash Arrays And Ef560 Flash Arrays

    Drive shelf or drive tray cabling | 77 Ports Cable Data rate and Number of Connector Type Length protocol connectors Expansion: MiniSAS to passive copper 2m or 1.5m MiniSAS 6 Gb/s SAS Drive channel redundancy for the E5500 controller drive trays, E5600 controller drive trays, EF550 flash arrays and EF560 flash arrays Controller-drive trays Each controller in these controller-drive trays and flash arrays has two drive expansion ports.
  • Page 86 78 | Hardware Cabling Guide Controller canister A Drive expansion ports (SAS drive expansion connectors) Controller Canister B Drive expansion ports (SAS drive expansion connectors) Drive trays The following figure shows the SAS ports on a DE1600 drive tray or a DE5600 drive tray. Each environmental services module (ESM) has two SAS-2 in ports and one SAS-2 expansion (out) port.

  • Page 87: Drive Tray Cabling Topologies For The E5524, E5512, E5612 And E5624 Controller-Drive Trays, And The Ef550 And Ef560 Flash Arrays

    Drive shelf or drive tray cabling | 79 ESM A ESM B SAS in ports SAS out (expansion) port Drive Shelves The following figures show the SAS ports on a DE212C drive shelf or a DE224C drive shelf. The I/O modules (IOMs) occupy the top half of the shelf.
  • Page 88 80 | Hardware Cabling Guide The EF550 controller-drive tray and the EF560 controller-drive tray can be cabled to the Note: DE5600 drive trays only. The total number of drives in the storage array, including the drives in the EF550 controller-drive tray or the EF560 controller-drive tray and those in all of the attached drive trays, must not exceed 120.
  • Page 89 Drive shelf or drive tray cabling | 81 One E5500 or E5600 controller drive tray or one EF550 or EF560 flash array and three drive trays...
  • Page 90 82 | Hardware Cabling Guide One E5500 or E5600 controller drive tray or one EF550 or EF560 flash array and up to 15 drive trays The previous figures show storage arrays with DE1600 drive trays or DE5600 drive trays. A storage array might also include DE6600 drive trays.

  • Page 91: Drive Tray Cabling Topologies For The E5560 Controller-Drive Tray And The E5660 Controller-Drive Tray

    Drive shelf or drive tray cabling | 83 storage array includes DE6600 drive trays, install those drive trays beginning from the bottom of the cabinet so that the cabinet does not become top-heavy. A top-heavy cabinet has a greater risk of falling over.
  • Page 92 84 | Hardware Cabling Guide One E5560 controller-drive tray or one E5660 controller-drive tray and one DE6600 drive tray...
  • Page 93 Drive shelf or drive tray cabling | 85 One E5560 controller-drive tray or one E5660 controller-drive tray and five DE6600 drive trays The figures above show storage arrays with DE6600 drive trays. A storage array with an E5560 controller-drive tray or an E5660 controller-drive tray might also include DE1600 drive trays or DE5600 drive trays.

  • Page 94: Drive Tray Cabling Topologies For The E5400 Controller-Drive Trays And The Ef540 Flash Array

    86 | Hardware Cabling Guide page 79 shows the arrangement of ESMs and the location of ports on the DE1600 drive trays and DE5600 drive trays. The figures above show storage arrays with DE6600 drive trays. A storage array with an E5560 controller-drive tray or an E5660 controller-drive tray might also include DE1600 drive trays or DE5600 drive trays.
  • Page 95 Drive shelf or drive tray cabling | 87 Controller canister A Drive expansion connector (connectors 2 and 4 comprise a redundant path pair.) Controller canister B Drive expansion connector (connectors 2 and 4 comprise a redundant path pair.) Redundant path pair on the E5460 controller-drive tray 92045-08 Controller canister A Drive expansion connector (connectors 2 and 4 comprise a redundant path pair.)

  • Page 96: Drive Tray Cabling Topologies For The E5424 Controller-Drive Tray, The E5412 Controller-Drive Tray, And Ef540 Flash Array

    88 | Hardware Cabling Guide SAS in - port 1 SAS in - port 2 SAS out (expansion) port ESM B The following figures show the SAS ports on a DE6600 drive tray. Each environmental services module (ESM) has two SAS in ports and one SAS expansion (out) port. You can connect the SAS in ports to the SAS expansion port on another drive tray or to the SAS expansion port on a controller- drive tray.
  • Page 97 Drive shelf or drive tray cabling | 89 SAS ports on a DE1600 drive tray or a DE5600 drive tray ESM A SAS IN - Port 1 SAS IN - Port 2 SAS Out (Expansion) Port ESM B One E5424 or E5412 controller-drive tray or one EF540 flash array and one DE1600 drive tray or DE5600 drive tray...
  • Page 98 90 | Hardware Cabling Guide One E5424 or E5412 controller-drive tray or one EF540 flash array and two DE1600 drive trays or DE5600 drive trays The following figures show the SAS ports on a DE6600 drive tray. You can connect either the left or right SAS port on an ESM to the SAS expansion port on another drive tray or on a controller-drive tray.
  • Page 99 Drive shelf or drive tray cabling | 91 ESM A ESM B SAS IN Ports SAS IN Ports SAS Out (Expansion) Port Warning: Risk of bodily injury – An empty tray weighs approximately 56.7 kg (125 lb). Three persons are required to safely move an empty tray. If the tray is populated with components, a mechanized lift is required to safely move the tray.
  • Page 100 92 | Hardware Cabling Guide One E5424 or E5412 controller-drive tray or one EF540 flash array and two DE6600 drive trays The following figure shows how the cabling pattern can be continued for additional drive trays until the 15 drive tray limit or the limit on the total number of drive slots in the storage array is reached. The figure uses the schematic representation for DE1600 drive trays or DE5600 drive trays.

  • Page 101: Drive Tray Cabling Topologies For The E5460 Controller-Drive Tray

    Drive shelf or drive tray cabling | 93 One E5424 or E5412 controller-drive tray or one EF540 flash array and seven or more DE6600 drive trays Drive tray cabling topologies for the E5460 controller-drive tray The figures in this section show representative cabling configurations. The configurations shown guarantee that redundant data paths exist between the controller-drive tray and all attached drive trays in a storage array.
  • Page 102 94 | Hardware Cabling Guide For any one controller-drive tray, you must not exceed the limit of 15 connected drive trays or the limit for the total number of drive slots in the storage array. The total numbers of drive slots is limited to 384.
  • Page 103 Drive shelf or drive tray cabling | 95 One E5460 controller-drive tray and two DE1600 or DE5600 drive trays The following figures show the SAS ports on a DE6600 drive tray. You can connect either of the SAS ports labeled SAS 1 and SAS 2 to the SAS Expansion port on another drive tray or on a controller- drive tray.
  • Page 104 96 | Hardware Cabling Guide SAS ports on a DE6600 drive tray ESM A ESM B SAS IN Port SAS IN Port SAS Expansion Ports One E5460 controller-drive tray and one DE6600 drive tray...
  • Page 105 Drive shelf or drive tray cabling | 97 One E5460 controller-drive tray and two DE6600 drive trays The following figure shows how the cabling pattern can be continued for additional drive trays until the 15 drive tray limit or the limit on the total number of drives in the storage array is reached. The figure uses the schematic representation for DE1600 drive trays or DE5600 drive trays.
  • Page 106 98 | Hardware Cabling Guide One E5460 controller-drive tray and seven or more DE6600 drive trays The following figure shows cabling for a storage array with the capacity for 384 drives, the maximum number. The storage array consists of a E5460 controller-drive tray with five DE6600 drive trays and one DE5600 drive tray.

  • Page 107: Drive Cabling Topologies For The E2800 Controller Shelves

    Drive shelf or drive tray cabling | 99 A storage array with the capacity for 384 drives using a E5460 controller-drive tray Drive cabling topologies for the E2800 controller shelves...

  • Page 108: Drive Channel Redundancy For The E2800 Controller Shelves

    100 | Hardware Cabling Guide This section provides examples of drive shelf cabling topologies for the E2800 controller shelves. The E2800 controller shelf models are the E2812, E2824, and E2860. The total number of drive bays in the storage array, including the drive bays in the controller shelf and those in the drive shelves, must not exceed 180.
  • Page 109 Drive shelf or drive tray cabling | 101 Controller A SAS port 1 SAS port 2 Controller B The following figure shows the drive ports (SAS expansion ports) on a dual-controller configuration for the E2860 controller shelf. The drive ports are at the far right of each controller. Controller A Controller B SAS port 1...
  • Page 110 102 | Hardware Cabling Guide SAS port 2 SAS port 3 SAS port 4 The following figure shows the SAS ports on a DE460C drive shelf. The I/O modules (IOMs) occupy the middle positions in the shelf Each IOM has four SAS-3 expansion ports. You can connect these ports to SAS-3 expansion ports on another drive shelf or to SAS expansion ports on a controller shelf.

  • Page 111: Drive Cabling Topologies For The E2824 Controller Shelf And The E2812 Controller Shelf

    Drive shelf or drive tray cabling | 103 Drive cabling topologies for the E2824 controller shelf and the E2812 controller shelf Depending on the number and type of drive shelves that you need to connect, see the applicable figure for a cabling topology. Each example shows a duplex controller shelf configuration with redundant paths to the drive shelves.

  • Page 112: Drive Cabling Topologies For The E2860 Controller Shelf

    104 | Hardware Cabling Guide One E2800 controller shelf and a single stack of SAS-2 drive shelves One E2800 controller shelf and dual stacks with a mix of SAS-2 and SAS-3 drive shelves Drive cabling topologies for the E2860 controller shelf Depending on the number and type of drive shelves that you need to connect, see the applicable figure for a cabling topology.
  • Page 113 Drive shelf or drive tray cabling | 105 One E2860 controller shelf and one SAS-3 drive shelf One E2860 controller shelf and a single stack of SAS-3 drive shelves One E2860 controller shelf and a single stack of SAS-2 drive shelves...

  • Page 114: Drive Tray Cabling Topologies For The E2700 Controller-Drive Trays

    106 | Hardware Cabling Guide One E2860 controller shelf and dual stacks with a mix of SAS-2 and SAS-3 drive shelves Drive tray cabling topologies for the E2700 controller-drive trays This section provides examples of drive tray cabling topologies for the E2700 controller-drive trays. The E2700 controller-drive tray models are: the E2712, the E2724 and the E2760.

  • Page 115: Drive Channel Redundancy For The E2700 Controller-Drive Trays

    Drive shelf or drive tray cabling | 107 Drive channel redundancy for the E2700 controller-drive trays Learn the physical features of the E2700 controller trays that support drive cabling to minimize the risk of losing access to data. Controller-drive trays Each controller in an E2712 or an E2724 controller-drive tray has two drive ports.
  • Page 116 108 | Hardware Cabling Guide SAS Drive Expansion Connector Drive trays The following figure shows the SAS ports on a DE1600 drive tray or a DE5600 drive tray. Each environmental services module (ESM) has two SAS-2 in ports and one SAS-2 expansion (out) port. You can connect the SAS in ports to the SAS expansion port on another drive tray or to the SAS expansion port on a controller-drive tray.

  • Page 117: Drive Tray Cabling Topologies For The E2712 Controller-Drive Tray And The E2724 Controller-Drive Tray

    Drive shelf or drive tray cabling | 109 SAS out (expansion) port Drive shelves The following figures show the SAS ports on a DE212C drive shelf or a DE224C drive shelf. The I/O modules (IOMs) occupy the top half of the shelf. Each IOM has four SAS-3 expansion ports. You can connect these ports to SAS-3 expansion ports on another drive shelf or drive tray or to SAS expansion ports on a controller shelf or controller-drive tray.
  • Page 118 110 | Hardware Cabling Guide The following figures shows the SAS ports on a DE1600 drive tray or a DE5600 drive tray. Note: You can connect either of the SAS ports labeled SAS 1 and SAS 2 to the SAS Expansion port on another drive tray or on a controller-drive tray.
  • Page 119 Drive shelf or drive tray cabling | 111 One E2700 controller-drive tray and two drive trays (dual stack configuration)
  • Page 120 112 | Hardware Cabling Guide One E2700 controller-drive tray and eight drive trays (dual stack configuration) The pattern shown can be extended to include additional drive trays as long as neither the limit on maximum number of drive slots nor the limit on maximum number of trays is exceeded.

  • Page 121: Drive Tray Cabling Topologies For The E2760 Controller-Drive Tray

    Drive shelf or drive tray cabling | 113 Drive tray cabling topologies for the E2760 controller-drive tray This section provides examples of drive tray cabling topologies for the E2760 controller-drive tray. The E2760 controller-drive tray can be cabled only to DE6600 drive trays. The total number of drives in the storage array, including the drives in the controller-drive tray and those in the drive trays, must not exceed 192.
  • Page 122 114 | Hardware Cabling Guide One E2760 controller-drive tray and one drive tray...

  • Page 123: Drive Tray Cabling Topologies For The E2600 Controller-Drive Trays

    Drive shelf or drive tray cabling | 115 One E2760 controller-drive tray and two drive trays (dual stack) Drive tray cabling topologies for the E2600 controller-drive trays Learn the physical features of the E2600 controller trays that support drive cabling to minimize the risk of losing access to data.

  • Page 124: Drive Channel Redundancy For The E2612 And E2624 Controller-Drive Trays

    116 | Hardware Cabling Guide Drive channel redundancy for the E2612 and E2624 controller-drive trays Controller-drive trays Each controller in an E2612 or E2624 controller-drive tray has one drive port. When a controller- drive tray has two controllers, the drive port on controller A and the drive port on controller B form a redundant pair.
  • Page 125 Drive shelf or drive tray cabling | 117 Controller A Controller B SAS drive expansion connector (connectors 3 and 4 comprise a redundant path pair) SAS drive expansion connector (connectors 3 and 4 comprise a redundant path pair) Drive trays The following figure shows the SAS ports on a DE1600 drive tray or a DE5600 drive tray.

  • Page 126: Drive Tray Cabling Topologies For The E2612 Controller-Drive Tray And The E2624 Controller-Drive Tray

    118 | Hardware Cabling Guide ESM A ESM B SAS in ports SAS out (expansion) port Drive tray cabling topologies for the E2612 controller-drive tray and the E2624 controller-drive tray Depending on the number of drive trays that you need to connect, see the applicable figure for a cabling topology.
  • Page 127 Drive shelf or drive tray cabling | 119 One E2600 controller-drive tray and one drive tray Controller A Controller B SAS IN SAS IN SAS IN SAS IN SAS EXP SAS EXP ESM B ESM A 98010-08 One E2600 controller-drive tray and two drive trays...
  • Page 128 120 | Hardware Cabling Guide One E2600 controller-drive tray and three drive trays...

  • Page 129: Drive Cabling Topologies For The E2660 Controller-Drive Tray With De6600 Drive Trays

    Drive shelf or drive tray cabling | 121 One E2600 controller-drive tray and eight drive trays Drive cabling topologies for the E2660 controller-drive tray with DE6600 drive trays Depending on the number of drive trays that you need to connect, see the applicable figure for a cabling topology.
  • Page 130 122 | Hardware Cabling Guide The following figures show the SAS ports on a DE6600 drive tray. You can connect either of the SAS ports labeled SAS 1 and SAS 2 to the SAS Expansion port on another drive tray or on a controller- drive tray.
  • Page 131 Drive shelf or drive tray cabling | 123 One E2660 controller-drive tray and one drive tray...

  • Page 132: Using Santricity Storage Manager To Add A Drive Tray To An Existing Storage Array

    124 | Hardware Cabling Guide One E2660 controller-drive tray and two drive trays Using SANtricity Storage Manager to add a drive tray to an existing storage array If you manage your storage array with SANtricity Storage Manager, use the tasks in this section to add a new drive tray to your storage array.

  • Page 133: Preparing To Add A Drive Tray

    Drive shelf or drive tray cabling | 125 Preparing to add a drive tray Steps for preparing to add a new drive shelf (drive tray) while power is still applied to the other components of a storage array. Before you begin Make sure that the power source for your storage array can accommodate the power requirements of Storage the new drive shelf (drive tray).

  • Page 134: Connecting The Drive Tray

    126 | Hardware Cabling Guide Option Description To install a drive tray that has Remove the drives before you continue with step on page 126. The previously been installed in a drives must be installed one at a time later in this procedure. storage array.
  • Page 135 Drive shelf or drive tray cabling | 127 Steps 1. Choose one of the following options: Option Description The new drive tray is the only Attach a cable between the SAS expansion port on controller A of the drive tray in a storage array controller-drive tray and a SAS IN port on ESM A of the new drive tray.

  • Page 136: Using Santricity System Manager To Add A Drive Shelf To An Existing Storage Array

    128 | Hardware Cabling Guide Option Description The new drive tray is the only Attach a cable between the SAS expansion port labeled Ch 2 on drive tray in a storage array controller A of the controller-drive tray and a SAS IN port on ESM B of with an E5500 or E5600 the new drive tray and then attach a cable between the SAS expansion controller-drive tray or an...

  • Page 137: Preparing To Add A Drive Shelf Or Drive Tray

    Drive shelf or drive tray cabling | 129 Preparing to add a drive shelf or drive tray Perform the following steps to prepare to add a new drive shelf (drive tray) using SANtricity System Manager while power is still applied to the other components of a storage array. Before you begin •...

  • Page 138: Installing The Drive Shelf Or Drive Tray And Applying Power

    130 | Hardware Cabling Guide Installing the drive shelf or drive tray and applying power Perform these steps for add a new drive shelf (drive tray) using SANtricity System Manager while power is still applied to the other components of a storage array. Steps 1.
  • Page 139 Drive shelf or drive tray cabling | 131 • If the new drive shelf or drive tray is the only drive shelf in the storage array, attach a cable between one of the SAS expansion ports on controller A of the controller shelf and a SAS expansion port 1 on IOM/ESM A of the new drive shelf.
  • Page 140 132 | Hardware Cabling Guide of the new drive shelf. Connect SAS expansion port 1 on IOM/ESM B of the new drive shelf to the SAS expansion port 1 on the drive shelf that was previously the last in the stack. •...

  • Page 141: Cabling For Out-Of-Band Management

    Cabling for out-of-band management This chapter provides examples of how to connect your storage array to an Ethernet network for out- of-band storage array management. If you plan to use in-band storage array management, Ethernet cabling might not be necessary for management connections. For illustrations showing the Ethernet port locations on the specific controller-drive tray model that Component locations you are installing, see the topics under...

  • Page 142: Fabric Out-Of-Band Ethernet Topology

    134 | Hardware Cabling Guide Fabric out-of-band Ethernet topology The following figure shows two storage array management connections from the controller-drive tray to two ports on an Ethernet switch. In this topology, the storage management station where the client software resides requires a NIC or some other Ethernet interface. You must use Ethernet cables for all storage array management connections.

  • Page 143: Hardware Installation For Synchronous Mirroring And Asynchronous Mirroring

    Hardware installation for Synchronous Mirroring and Asynchronous Mirroring The Asynchronous Mirroring feature uses a remote point-in-time replication method. Asynchronous Mirroring differs from Synchronous Mirroring in one essential way: it captures the state of the source volume at a particular point in time and includes just the data that has changed since the last image capture.

  • Page 144: Iscsi Connections For Asynchronous Mirroring

    136 | Hardware Cabling Guide iSCSI connections for Asynchronous Mirroring You can use iSCSI connections for the Asynchronous Mirroring feature. Connect one iSCSI port on each controller of the local (primary) storage array to the corresponding controller on the remote (secondary) storage array.
  • Page 145 Hardware installation for Synchronous Mirroring and Asynchronous Mirroring | 137 For more information about Fibre Channel switch zoning or setting up a zone configuration, refer to the manufacturer’s documentation that is provided with the switch. Because of the varying Synchronous Mirroring configurations, the switch zone settings are presented preceding each configuration in this appendix.

  • Page 146: Highest Availability Campus Configuration Recommended

    138 | Hardware Cabling Guide Configuration Description Highest availability This configuration has the greatest redundancy. It is the most stable of the campus configuration three configurations. (recommended) • Two Fibre Channel switches (for a total of four) at both the primary site and the secondary site provide for complete failover and redundancy in the Fibre Channel switches and fabrics, in addition to all storage array components and hosts.
  • Page 147 Hardware installation for Synchronous Mirroring and Asynchronous Mirroring | 139 This configuration has two Fibre Channel switches at the primary site and two Fibre Channel switches at the secondary site (four switches total), which provide for complete failover and redundancy. Failures could involve Fibre Channel switches, Fibre Channel cables, and any host or storage array.
  • Page 148 140 | Hardware Cabling Guide Switch zoning for highest availability campus configuration The highest availability campus configuration provides a separate zone for each reserved port for the Synchronous Mirroring feature or the Asynchronous Mirroring feature. The switches do not need to be zoned exactly as presented in this configuration. However, you must meet the following requirements when zoning switches for the highest availability campus configuration.
  • Page 149 Hardware installation for Synchronous Mirroring and Asynchronous Mirroring | 141 Cabling for the highest availability campus configuration After the four Fibre Channel switches are correctly zoned, set up the highest availability campus configuration for the Synchronous Mirroring feature or the Asynchronous Mirroring feature. About this task Start the installation at the primary site.
  • Page 150 142 | Hardware Cabling Guide Ho s t Gro u p Ho s t 1 Ho s t 2 HBA1a HBA1b HBA2a HBA2b S witc h 1 10 12 Zo n e 2 Zo ne 1 13 15 Zo ne 3 Zo ne 4 S witc h 2 10 12...
  • Page 151 Hardware installation for Synchronous Mirroring and Asynchronous Mirroring | 143 Controller port A2 and controller port B2 are reserved for mirror relationship Note: synchronization upon activation of the Synchronous Mirroring feature. In a four-host-port system, controller port A4 and controller port B4 are reserved. The primary site cabling is now complete.

  • Page 152: Campus Configuration

    144 | Hardware Cabling Guide 12. Repeat Step on page 143 for switch 2A and switch 2B to complete the fabric environment for switch 2. Cabling for the highest availability campus configuration is complete. 13. Repeat Step on page 141 through Step on page 143 for other storage arrays that exist in the same cabinet that use the Synchronous Mirroring feature or the Asynchronous Mirroring feature.
  • Page 153 Hardware installation for Synchronous Mirroring and Asynchronous Mirroring | 145 Host Fibre Channel cable Storage array Fibre Channel cable Fibre Channel cable dedicated for mirroring Fabric uplink cable Switch zoning for the campus configuration The campus configuration allows for a separate zone for each reserved port for the Synchronous Mirroring feature or the Asynchronous Mirroring feature.
  • Page 154 146 | Hardware Cabling Guide You must configure the zones on the switches so that there is one port per zone for a storage array connection and one port per zone for each host. You must zone the switches so that a single host adapter can access only one controller per storage array.
  • Page 155 Hardware installation for Synchronous Mirroring and Asynchronous Mirroring | 147 Complete all connections by using Fibre Channel cables of the correct length. Note: Steps 1. Determine whether you adding equipment for mirroring to an existing storage array environment. • If so, stop I/O activity from all hosts before proceeding. Go to Step on page 147.
  • Page 156 148 | Hardware Cabling Guide following Step on page 148 shows the cabling configuration schematically with four host ports on each of two controllers in each controller-drive tray. 7. Connect controller port B1 of the storage array to an available port in zone 2 of switch 1A. 8.

  • Page 157: Intra-Site Configuration

    Hardware installation for Synchronous Mirroring and Asynchronous Mirroring | 149 Switch 1B Switch 1A Fabric 1 10 12 Zone 1 Zone 2 Zone 1 Zone 2 13 15 Zone 3 Zone 3 84004-06 Zone 4 Zone 4 Cabling for the campus configuration is complete. 12.
  • Page 158 150 | Hardware Cabling Guide Host Fibre Channel cable Storage array Fibre Channel cable Fibre Channel cable dedicated for mirroring Switch zoning for the intra-site configuration The intra-site configuration provides switch redundancy, but the switches are not cascaded and are independent of each other.
  • Page 159 Hardware installation for Synchronous Mirroring and Asynchronous Mirroring | 151 Before proceeding, review the requirements in this section and the zoning example in the figures to make sure that both switches are correctly zoned. For more information, see Fibre Channel Configurations Overview on page 136.
  • Page 160 152 | Hardware Cabling Guide 5. Connect the secondary host bus adapter for each host to an available port in zone 1 of switch 2. The following figure shows the cabling that is described in this step. 6. Connect controller port A1 of the primary storage array to an available port in zone 1 of switch 1.
  • Page 161 Hardware installation for Synchronous Mirroring and Asynchronous Mirroring | 153 The following figure shows the cabling that is described in Step on page 152 through Step page 153. Host Fibre Channel cable Storage array Fibre Channel cable Fibre Channel cable dedicated for mirroring 7.

  • Page 162: Installing And Using Mirroring With A Wide Area Network

    154 | Hardware Cabling Guide Host Fibre Channel cable Storage array Fibre Channel cable Fibre Channel cable dedicated for mirroring Cabling for the intra-site configuration is complete. 14. Repeat Step on page 151 through Step on page 153 for any additional storage arrays that exist in the same cabinet that will use the Synchronous Mirroring feature or the Asynchronous Mirroring feature.
  • Page 163 Hardware installation for Synchronous Mirroring and Asynchronous Mirroring | 155 • The smaller the bandwidth on the WAN, the longer it takes a mirror to synchronize. • If the bandwidth does not exceed the average rate, you might not be able to synchronize the data at all.

  • Page 164: Copyright Information

    Copyright information © Copyright 1994–2016 NetApp, Inc. All rights reserved. Printed in the U.S. No part of this document covered by copyright may be reproduced in any form or by any means— graphic, electronic, or mechanical, including photocopying, recording, taping, or storage in an electronic retrieval system—without prior written permission of the copyright owner.

  • Page 165: Trademark Information

    Trademark information NetApp, the NetApp logo, Go Further, Faster, AltaVault, ASUP, AutoSupport, Campaign Express, Cloud ONTAP, Clustered Data ONTAP, Customer Fitness, Data ONTAP, DataMotion, Fitness, Flash Accel, Flash Cache, Flash Pool, FlashRay, FlexArray, FlexCache, FlexClone, FlexPod, FlexScale, FlexShare, FlexVol, FPolicy, GetSuccessful, LockVault, Manage ONTAP, Mars, MetroCluster, MultiStore, NetApp Insight, OnCommand, ONTAP, ONTAPI, RAID DP, RAID-TEC, SANtricity, SecureShare, Simplicity, Simulate ONTAP, Snap Creator, SnapCenter, SnapCopy, SnapDrive, SnapIntegrator, SnapLock, SnapManager, SnapMirror, SnapMover, SnapProtect, SnapRestore,...

  • Page 166: How To Send Comments About Documentation And Receive Update Notifications

    How to send comments about documentation and receive update notifications You can help us to improve the quality of our documentation by sending us your feedback. You can receive automatic notification when production-level (GA/FCS) documentation is initially released or important changes are made to existing production-level documents. If you have suggestions for improving this document, send us your comments by email.

Table of Contents
