Quantum StorNext QD7000 Installation Manual

Hide thumbs Also See for StorNext QD7000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
DC Power Installation and AC-to-DC
Power Conversion Guide
StorNext QD7000
Firmware 8.40.xx.xx
6-68674-01 Rev A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the StorNext QD7000 and is the answer not in the manual?

Questions and answers

Related Manuals for Quantum StorNext QD7000

Summary of Contents for Quantum StorNext QD7000

  • Page 1 DC Power Installation and AC-to-DC Power Conversion Guide StorNext QD7000 Firmware 8.40.xx.xx 6-68674-01 Rev A...
  • Page 2 Artico, Be Certain (and the Q brackets design), DLT, DXi, DXi Accent, DXi V1000, DXi V2000, DXi V4000, GoVault, Lattus, NDX, the Q logo, the Q Quantum logo, Q-Cloud, Quantum (and the Q brackets design), the Quantum logo, Quantum Be Certain (and the Q...
  • Page 3 (E5600, Titan RAID controller, only). Refer to the NetApp to Quantum Naming Decoder section for additional information. This section provides the following information: • Audience • Prerequisites • NetApp to Quantum Naming Decoder • Product Safety Statements • Contacts • Comments • Quantum Global Services Audience This manual is intended for storage customers and technicians.
  • Page 4 Product Quantum-Storage Description Controller-Drive Tray Base System Quantum uses Base System when referring to a drive tray with the RAID controllers. Drive Tray Expansion Unit Quantum uses Expansion Unit when referring to a drive tray with the environmental services modules (ESMs).
  • Page 5 Preface E-Series NetApp Product Quantum-Storage Description E5660 Quantum StorNext QD7000 • DE6600 4U drive enclosure • With E5600 RAID controllers (Titan) E5560 Quantum StorNext QD7000 • DE6600 4U drive enclosure • With E5500 RAID controllers (Soyuz) E5460 Quantum StorNext QD6000 •...
  • Page 6 (Pikes Peak) Product Safety Quantum will not be held liable for damage arising from unauthorized Statements use of the product. The user assumes all risk in this aspect. This unit is engineered and manufactured to meet all safety and regulatory requirements.
  • Page 7 Preface DC Power Installation and AC-to-DC Power Conversion Guide...
  • Page 8 Benefit today at: http://www.quantum.com/serviceandsupport/get-help/ index.aspx#contact-support • eSupport - Submit online service requests, update contact information, add attachments, and receive status updates via email. Online Service accounts are free from Quantum. That account can viii DC Power Installation and AC-to-DC Power Conversion Guide...
  • Page 9 Preface also be used to access Quantum’s Knowledge Base, a comprehensive repository of product support information. Get started at: http://www.quantum.com/customercenter/ For further assistance, or if training is desired, contact the Quantum Customer Support Center: North America 1-800-284-5101 (toll free) +1-720-249-5700...
  • Page 10 E-Series Systems DC Power Installation and AC-to-DC Power Conversion Guide NetApp, Inc. Telephone: +1 (408) 822-6000 Part number: 215-09441_A0 495 East Java Drive Fax: +1 (408) 822-4501 Release date: December 2014 Sunnyvale, CA 94089 Support telephone: +1 (888) 463-8277 U.S. Web: http://www.netapp.com Feedback: doccomments@netapp.com...

  • Page 12: Table Of Contents

    Table of Contents Deciding whether to use this guide..........................1 How to send your comments............................2 DC Power Supplies................................ 3 DC Power Source Precautions..........................3 Installing a Controller-Drive Tray or a Drive Tray with the DC Power Option............4 Connecting the DC Power Cords..........................4 AC-to-DC Power Supply Conversion...........................
  • Page 13 ii - Table of Contents...

  • Page 14: Deciding Whether To Use This Guide

    Deciding whether to use this guide This guide includes information about installing a DC power source, converting from an AC to a DC power source, and replacing a failed DC power source. Use this guide to install, convert or replace a DC power source into an industry-standard cabinet.

  • Page 15: How To Send Your Comments

    How to send your comments You can help us to improve the quality of our documentation by sending us your feedback. Your feedback is important in helping us to provide the most accurate and high-quality information. If you have suggestions for improving this document, send us your comments by email to doccomments@netapp.com. To help us direct your comments to the correct division, include in the subject line the product name, version, and operating system.

  • Page 16: Dc Power Supplies

    DC Power Supplies This document is a supplement for NetApp® storage arrays that can use a DC power source. A DC power source uses a DC input to supply power to DC-powered power-fan canisters. The DC voltage input is –48-Vdc. This document provides the following information: A list of DC power compatible trays Installing DC power trays...

  • Page 17: Installing A Controller-Drive Tray Or A Drive Tray With The Dc Power Option

    Installing a Controller-Drive Tray or a Drive Tray with the DC Power Option To install your controller-drive tray or drive tray with the DC power option, you must follow the procedures in the hardware installation guide for your tray. When you reach the procedure in that guide for connecting the power cords, use the following procedure to connect the DC power cords rather than the procedure in the document for AC power cords.
  • Page 18 c. Connect the green and yellow ground wire to the ground terminal. Figure 1. DC Power Connector Cable and Source Wires 1. Supply (Negative), Brown Wire, –48 VDC 2. Return (Positive), Blue Wire 3. Ground, Green and Yellow Wire 4. DC Power Connector 4.

  • Page 19: Ac-To-Dc Power Supply Conversion

    AC-to-DC Power Supply Conversion This procedure assumes that the tray you are converting is not installed in a rack and is not in use as part of a storage array. To convert from an AC power source to a DC power source, perform the following procedures in the order provided. 1.
  • Page 20 2. Remove the AC power-fan canisters that are in the tray to be converted. Figure 2. Power-Fan Canister and Controller Canister 1. Controller Canister 2. Power-Fan Canister a. Unlock and pull out the release levers to release the power-fan canister from the chassis. b.

  • Page 21: Turning On The Power To The Trays

    4. Install the tray into the rack. For information about installing the tray, refer to the hardware installation guide. Turning on the Power to the Trays 1. Turn on the power switch on the rear of each drive tray that is connected to the controller-drive tray. 2.
  • Page 22 1. Wait until the LEDs stop blinking from normal start-up before checking for faults. Figure 5. LEDs on a DC Power-Fan Canister 1. Standby Power LED (Green) 2. Power-Fan Output DC Power LED (Green) 3. Power-Fan Service Action Allowed LED (Blue) 4.
  • Page 23 Yes – Click the Recovery Guru toolbar button in the Array Management Window, and complete the recovery procedure. If the problem has not been resolved, contact your Technical Support Representative. No – Go to step 15. 15. Check the LEDs on the front and the rear of each tray. All of the green LEDs should be on, and all of the amber LEDs should be off.

  • Page 24: Removing And Replacing A Failed Dc Power-Fan Canister

    Removing and Replacing a Failed DC Power-Fan Canister Before you replace the power-fan canister, gather antistatic protection and a replacement power-fan canister. ATTENTION Possible equipment damage – If you perform this procedure with the power turned on, you must complete it within three minutes to prevent the possibility of overheating the equipment. You can determine whether you have a failed power-fan canister in two ways: The Recovery Guru directs you to replace a failed power-fan canister.
  • Page 25 For more information about this command, refer to the Command Line Interface and Script Commands Programming Guide. 2. Did the Recovery Guru direct you to replace a failed power-fan canister? Yes – Go to step 4. No – Run the Recovery Guru to identify the failed component, and go to step 3. 3.

  • Page 26: Installing A New Dc Power-Fan Canister

    8. Turn off the Power switch on the power-fan canister that has failed. Figure 8. Power Switch on the Power-Fan Canister 1. Power Switch 9. Remove the plastic strain relief from the power cord. 10. Unplug the power cord from the failed power-fan canister. 11.
  • Page 27 6. Turn on the 30-amp circuit breaker between the power-fan canister and the DC power source. 7. Check the green Input DC Power LED and the amber Power Service Action Required LED on the new power-fan canister. Figure 10. Power-Fan Canister Service Action LEDs 1.

  • Page 28: Regulatory Compliance Statements

    Regulatory Compliance Statements FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial installation.
  • Page 29 Japan Electronics And Information Technology Industries Association (JEITA) Power Cable Statement Translation of JEITA Power Cable notice.: Do not use power cord with other products. Translation of notice: Use only NetApp supplied power cords with NetApp equipment. Compliance with the Spanish Royal Decree 106/2008 Este aviso se proporciona de conformidad con, además de otros requisitos, el Real Decreto español 106/2008: El precio de venta al público de las baterías, los acumuladores y las celdas de potencia incluye el coste de la gestión de su desecho.

  • Page 30: Trademark Information

    Trademark information NetApp, the NetApp logo, Network Appliance, the Network Appliance logo, Akorri, ApplianceWatch, ASUP, AutoSupport, BalancePoint, BalancePoint Predictor, Bycast, Campaign Express, ComplianceClock, Cryptainer, CryptoShred, CyberSnap, Data Center Fitness, Data ONTAP, DataFabric, DataFort, Decru, Decru DataFort, DenseStak, Engenio, Engenio logo, E-Stack, ExpressPod, FAServer, FastStak, FilerView, Flash Accel, Flash Cache, Flash Pool, FlashRay, FlexCache, FlexClone, FlexPod, FlexScale, FlexShare, FlexSuite, FlexVol, FPolicy, GetSuccessful, gFiler, Go further, faster, Imagine Virtually Anything, Lifetime Key Management, LockVault, Manage ONTAP, Mars, MetroCluster, MultiStore, NearStore, NetCache, NOW (NetApp on the Web), Onaro, OnCommand,...

  • Page 31: Copyright Information

    Copyright information Copyright © 1994–2014 NetApp, Inc. All rights reserved. Printed in the U.S. No part of this document covered by copyright may be reproduced in any form or by any means— graphic, electronic, or mechanical, including photocopying, recording, taping, or storage in an electronic retrieval system—without prior written permission of the copyright owner.
