10. Maintenance
10.1.

Assembly tool for seat seal

! By means of the assembly tool, the upper seat seal (pos. 16)
can be installed, only (see chapter 14.1).
To simplify the installation of the seat seal, the following
assembly tool is available.
DN
25
40
50
65
80, 100
assembly tool SDM4
Inch reference number
1" 000 51-13-226/17
1,5" 000 51-13-227/17
2" 000 51-13-228/17
2,5" 000 51-13-229/17
3" 000 51-13-230/17
4" 000 51-13-225/17
UK
ID No.
H314439
H314440
H314441
H311447
H314442
H314443
