Select I/O Modules

Add and Configure Standard I/O Modules
Topic
Select I/O Modules
Validate Standard I/O Layout
Configure Standard I/O
Configure Standard Distributed I/O Modules on an EtherNet/IP Network
Configure Standard Distributed I/O Modules on a DeviceNet Network
Monitor Standard I/O Modules
Compact GuardLogix® 5370 controller systems offer these standard I/O
module options:
•

Local Expansion Modules

• Standard Distributed I/O Modules Over an EtherNet/IP Network
• Standard Distributed I/O Modules Over a DeviceNet Network
Local Expansion Modules
Compact GuardLogix 5370 controller systems support the use of standard
Compact I/O™ modules as local expansion modules along a CompactBus
backplane.
Consider the following when using local expansion modules:
• The controllers support this many local Compact I/O modules across
up to three I/O banks, that is, the local bank and two more banks.
Cat. No.
1769-L30ERMS
1769-L33ERMS
1769-L33ERMSK
1769-L36ERMS
(1)
1769-L37ERMS
(1)
1769-L38ERMS
1769-L33ERMOS
1769-L36ERMOS
(1)
1769-L37ERMOS
(1)
1769-LE8ERMOS
(1) Available at firmware revision 31.
Rockwell Automation Publication 1769-UM022C-EN-P - June 2018
Local Expansion Modules Supported, max
8
16
30
—
6
Chapter
Page
83
86
96
98
100
103
83
