Warranty - Binary B-200-1CAT-HDIR Owner's Manual

SPECIFICATIONS
Technical
HDMI Compliance
HDCP Compliance
Video Bandwidth
Video Support
HDMI over UTP Transmission (24-bit)
Audio Support
Signal Equalization
Input TMDS Signal
Input DDC Signal
ESD Protection
PCB Stack-Up
IR Pass-Through
Input
Output
HDMI Source Control
IR Remote Control
HDMI Connector
RJ45 Connector
3.5mm Connector
Rotary Control Switch
Mechanical
Housing
Dimensions (L x W x H)
Weight
Power Supply
Power Consumption
Operation Temperature
Storage Temperature
Relative Humidity
*Note: Specifications are subject to change without notice. Dimensions and weight are approximate.

WARRANTY

2-Year Limited Warranty
This Binary™ Product has a Two-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to
be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products which have been
abused, modified or disassembled. Products to be repaired under this warranty must be returned to SnapAV or a designated service
center with prior notification and an assigned return authorization number (RA).
For Technical Support: 1-866-838-5052
Transmitter
Single-link 225MHz (6.75Gbps)
480i / 480p / 720p / 1080i / 1080p60
Full HD (1080p)-130ft (CAT5e) / 165ft (CAT6)
HD (720p/1080i)- 165ft (CAT5e) / 200ft (CAT6)
Surround sound (up to 7.1ch) or stereo digital audio
(1) Human body model — ±19kV (air-gap discharge) & ±12kV (contact discharge) (2)
4-layer board (impedance control — differential 100Ω; single 50Ω)
1x HDMI, 1x 3.5mm
1x RJ45, 1x 3.5mm
Controllable via IR pass-through from RX to TX with IR extenders
WE/SS 8P8C with 2 LED indicators
IR transmitter
Mode
Tx and Rx each 2.9" x 3.5" x 1"
20~90% RH (no condensation)
HDMI 1.4 3D
Yes
8-level digital control at RX
1.2 Volts (peak-to-peak)
5 Volts (peak-to-peak, TTL)
Core chipset — ±8kV
Bi-directional
1x RJ45, 1x 3.5mm
1x HDMI, 1x 3.5mm
Carrier frequency: 20-60kHz
Type A (19-pin female)
Metal enclosure
Tx and Rx each 1.1 lbs
5V DC 2A
3 Watt (max)
32~104°F
-4~140°F
Receiver
IR receiver
Signal level
111228
