Terminal Identification - Altronix ALTV248UL Installation Manuals

WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture. This
installation should be made by qualified service personnel and should conform to the National Electrical
Code and all local codes. Use 75ºC or higher rated UL insulated wiring for connecting the unit to the
mains. Replace fuses with the same type and rating (Eight (8) Output ALTV248UL Reference Chart, pg. 2).
PD4 - Power Distribution Module
Terminal Legend Function/Description
1P - 4P AC output
1N - 4N AC output
PD8 - Power Distribution Module
Terminal Legend Function/Description
1P - 8P AC output
1N - 8N AC output
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- 4 -

Terminal Identification:

CAUTION: To reduce the risk of electric shock do not open enclosure. There are no
user serviceable parts inside. Refer servicing to qualified service personnel.
