Enclosure Dimensions (H x W x D) for:
• ALTV248UL • ALTV248ULCB
8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm)
Enclosure Dimensions (H x W x D) for:
• ALTV248300ULM • ALTV248300ULCBM
8.5" x 7.5" x 3.75" (215.9mm x 190.5mm x 97.9mm)
ALTV248ULseries
0.6"
1.25"
(31.75mm) (15.24mm)
1.125"
(28.575mm)
2"
(50.8mm)
2"
(50.8mm)
8.125"
(206.375mm)
(25.4mm)
0.6"
(15.24mm)
0.6"
1.25" (15.24mm)
(31.75mm)
1"
(25.4mm)
0.9"
(22.86mm)
8.13"
(206.5mm)
1"
(25.4mm)
0.6"
1.25"
(15.24mm)
(31.75mm)
3.85"
(97.79mm)
