Fig. 10
ALTV248600ULCB
Connected
to Door
24VAC configuration
Class 2 Not Wet/Class 3 Wet
Green
Lead
(Ground)
115VAC input,
60 Hz.
- 10 -
24VAC or 28VAC output 1
(Follow same procedure using terminals 2P & N
through 4P & N outputs 2 through 4)
non power-limited
XFMR*
Black
Lead
White
non power-limited
Lead
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
Illuminated Power Disconnect
Circuit Breaker with manual reset
non power-limited
XFMR*
Fig. 10a
ALTV248ULseries
