Fig. 1
ALTV248UL
24VAC or 28VAC
output 1 (Follow
same procedure using
terminals 2P & N
through 8P & N
outputs 2 through 8)
Primary
In-line
Fuse
Fig. 2
ALTV248ULCB
24VAC or 28VAC
output 1
(Follow same
procedure using
terminals 2P & N
through 8P & N
outputs 2 through 8)
Primary
In-line
Fuse
ALTV248ULseries
F U S E D P O W E R O U T P U T S
C O M M O N P O W E R O U T P U T S
Class 1 Outputs
non-power
limited
XFMR
Back Panel of Enclosure
F 1 F 2 F 3 F 4 F 5 F 6
P
F U S E D P O W E R O U T P U T S
N
C O M M O N P O W E R O U T P U T S
24VAC configuration Class 2 Not Wet/Class 3 Wet
28VAC configuration Class 1
non-power
limited
XFMR
Back Panel of Enclosure
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
N P S
non-power
limited
Black
Lead
Black
Lead
115VAC Input,
60 Hz.
White
Lead
Green
Lead
(Ground)
F 7 F 8
D1
LED
R1
INPUT
N P S
non-power
limited
Black
Lead
Black
Lead
115VAC Input,
60 Hz.
White
Lead
Green
Lead
(Ground)
Fig. 1a
Fig. 2a
- 5 -
