ALTV248220 Series
CCTV Power Supplies
Installation Guide
Models Include:
• ALTV248220
- 24VAC @ 4A (100VA)
or 28VAC @ 3.5A.
- Eight (8) Fuse Protected Outputs.
• ALTV248175220
- 24VAC @ 7.25A (175VA)
or 28VAC @ 6.25A (175VA).
- Eight (8) Fuse Protected Outputs.
• ALTV248300220
- 24VAC @ 14A (350VA)
or 28VAC @ 12.5A (350VA).
- Eight (8) Fuse Protected Outputs.
• ALTV248300M220
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (300VA).
- Eight (8) Fuse Protected Outputs.
• ALTV248600220
- 24VAC @ 28A (700VA)
or 28VAC @ 25A (700VA).
- Eight (8) Fuse Protected Outputs.
• ALTV248CB220
- 24VAC @ 4A (100VA)
or 28VAC @ 3.5A.
- Eight (8) PTC Protected Outputs.
• ALTV248175CB220
- 24VAC @ 7.25A (175VA)
or 28VAC @ 6.25A (175VA).
- Eight (8) PTC Protected Outputs.
• ALTV248300CB220
- 24VAC @ 14A (350VA)
or 28VAC @ 12.5A (350VA).
- Eight (8) PTC Protected Outputs.
• ALTV248300CBM220
- 24VAC @ 12.5A (300VA)
or 28VAC @ 10A (300VA).
- Eight (8) PTC Protected Outputs.
• ALTV248600CB220
- 24VAC @ 20A (480VA)
or 28VAC @ 20A (560VA).
- Eight (8) PTC Protected Outputs.
Rev. 040904
Advertisement
Related Manuals for Altronix ALTV248220 Series
Summary of Contents for Altronix ALTV248220 Series
- Page 1 ALTV248220 Series CCTV Power Supplies Installation Guide Models Include: • ALTV248220 • ALTV248CB220 - 24VAC @ 4A (100VA) - 24VAC @ 4A (100VA) or 28VAC @ 3.5A. or 28VAC @ 3.5A. - Eight (8) Fuse Protected Outputs. - Eight (8) PTC Protected Outputs.
-
Page 2: Specifications
Overview: ALTV248220 Series CCTV Power Supplies provide 24VAC/28VAC distributed via eight (8) fuse or PTC protected outputs for powering CCTV cameras, heaters, and other video accessories. Eight (8) Output ALTV248220 Reference Chart: Total Output 220VAC Output Number Fuse Current Main Fuse... -
Page 3: Installation Instructions
Installation Instructions: 1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure’s upper keyholes over the two upper screws, level and secure. - Page 4 ALTV248220 • ALTV248CB220 Fig. 1 - Used on PTC Models (ALTV248CB220) F U S E D P O W E R O U T P U T S 24VAC or 28VAC fused output 1 INPUT C O M M O N P O W E R O U T P U T S INPUT...
- Page 5 ALTV248300220 • ALTV248300CB220 Fig. 3 - Used on PTC Models (ALTV248300CB220) F U S E D P O W E R O U T P U T S NPUT C O M M O N P O W E R O U T P U T S 24VAC or 28VAC fused output 1 (Follow same procedure using...
- Page 6 ALTV248600220 • ALTV248600CB220 Fig. 5 - Used on PTC Models (ALTV248600CB220) Power Switch XFMR* XFMR* Red Lead Black Lead 250V 220VAC Input 50/60 Hz Terminal Blocks for Fig. 1, 2, 3, and 4 Terminal Blocks for Fig. 5 24VAC or 28VAC fused or PTC protected outputs 1 through 4.
- Page 7 Enclosure Dimensions for: 7.25” (184.15mm) 3.625” • ALTV248220 (184.15mm) • ALTV248CB220 1.25” (31.75mm) 8.5” x 7.5” x 3.5” 3.5” (88.9mm) (215.9mm x 190.5mm x 88.9mm) 1.25” 0.6” 0.6” 6.05” (15.24mm) (15.24mm) (31.75mm) (153.67mm) 1.125” 1.125” (28.575mm) (28.575mm) 2” (50.8mm) 2” (50.8mm) 8.125”...
- Page 8 1.0” (25mm) (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A. II1ALTV248220series A12P MEMBER - 8 - ALTV248220series...
