ALTV248220 Series
CCTV Power Supplies
Installation Guide
Models Include:
ALTV248220
- 24VAC @ 4A (100VA) or
28VAC @ 3.5A (100VA).
- Eight (8) Fuse Protected Outputs.
ALTV248175220
- 24VAC @ 7.25A (175VA) or
28VAC @ 6.25A (175VA).
- Eight (8) Fuse Protected Outputs.
ALTV248300220
- 24VAC @ 14A (350VA) or
28VAC @ 12.5A (350VA).
- Eight (8) Fuse Protected Outputs.
ALTV248300M220
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (300VA).
- Eight (8) Fuse Protected Outputs.
ALTV248600220
- 24VAC @ 28A (700VA) or
28VAC @ 25A (700VA).
- Eight (8) Fuse Protected Outputs.
Rev. 040904
ALTV248CB220
- 24VAC @ 4A (100VA) or
28VAC @ 3.5A (100VA).
- Eight (8) PTC Protected Outputs.
ALTV248175CB220
- 24VAC @ 7.25A (175VA) or
28VAC @ 6.25A (175VA).
- Eight (8) PTC Protected Outputs.
ALTV248300CB220
- 24VAC @ 14A (350VA) or
28VAC @ 12.5A (350VA).
- Eight (8) PTC Protected Outputs.
ALTV248300CBM220
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (300VA).
- Eight (8) PTC Protected Outputs.
ALTV248600CB220
- 24VAC @ 28A (700VA) or
28VAC @ 25A (700VA).
- Eight (8) PTC Protected Outputs.
More than just power.
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix ALTV248220 Series
Summary of Contents for Altronix ALTV248220 Series
- Page 1 ALTV248220 Series CCTV Power Supplies Installation Guide Models Include: ALTV248220 ALTV248CB220 - 24VAC @ 4A (100VA) or - 24VAC @ 4A (100VA) or 28VAC @ 3.5A (100VA). 28VAC @ 3.5A (100VA). - Eight (8) Fuse Protected Outputs. - Eight (8) PTC Protected Outputs.
-
Page 2: Specifications
Overview: Altronix ALTV248220 Series CCTV Power Supplies provide 24VAC or 28VAC distributed via eight (8) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories. Eight (8) Output ALTV248220 Reference Chart: Altronix Model Number 24VAC ALTV248220 –... -
Page 3: Installation Instructions
(servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. ALTV248220 Series - 3 -... - Page 4 ALTV248CB220 250V Input 220VAC 50/60Hz, 0.5A Voltage Selection Terminal Blocks for Fig. 1 Configuration 24VAC Output (Yellow) (Black) 24VAC or 28VAC fused or PTC 28VAC protected outputs 1 through 8. Output (Black) (Yellow) - 4 - ALTV248220 Series...
- Page 5 Illuminated Power Switch 250V Input 220VAC 50/60Hz, 0.7A Voltage Selection Terminal Blocks for Fig. 2 Configuration 24VAC Output (Yellow) (Black) 24VAC or 28VAC fused or PTC 28VAC protected outputs 1 through 8. Output (Black) (Yellow) ALTV248220 Series - 5 -...
- Page 6 Illuminated Power Switch 250V Input 220VAC, 50/60Hz, 1.35A Voltage Selection Terminal Blocks for Fig. 3 Configuration 24VAC Output (Yellow) (Black) 24VAC or 28VAC fused or PTC 28VAC protected outputs 1 through 8. Output (Black) (Yellow) - 6 - ALTV248220 Series...
- Page 7 250V Input used on 220VAC ALTV248300CBM220 50/60Hz, 1.35A Voltage Selection Terminal Blocks for Fig. 4 Configuration 24VAC Output (Yellow) (Black) 24VAC or 28VAC fused or PTC 28VAC protected outputs 1 through 8. Output (Black) (Yellow) ALTV248220 Series - 7 -...
-
Page 8: Voltage Selection
Illuminated Power Switch 250V Input 220VAC, 50/60Hz, 2.7A Voltage Selection Terminal Blocks for Fig. 5 Configuration 24VAC Output (Yellow) (Black) 24VAC or 28VAC fused or PTC protected outputs 1 through 4. 28VAC Output (Black) (Yellow) - 8 - ALTV248220 Series... - Page 9 (15.24mm) (31.75mm) (153.67mm) 1.125” 1.125” (28.575mm) (28.575mm) 2” (50.8mm) 2” (50.8mm) 8.125” (206.375mm) 1” 1” (25.4mm) (25.4mm) 6.05” 0.6” 0.6” 1.25” (153.67mm) (15.24mm) (15.24mm) (31.75mm) 3.5” (88.9mm) 1” (25.4mm) 1” 5.25” 1” (25.4mm) (133.35mm) (25.4mm) ALTV248220 Series - 9 -...
- Page 10 1” (25.4mm) (25.4mm) 0.9” 0.9” (22.86mm) (22.86mm) 8.13” 8.13” (206.5mm) (206.5mm) 1.75” (44.45mm) 1” 1” (25.4mm) (25.4mm) 0.6” 1.25” 0.6” (15.24mm) (31.75mm) (15.24mm) 3.85” (97.79mm) 3.85” (97.79mm) 1” (25.4mm) 1” 1” (25.4mm) (25.4mm) 7.25” (184.15mm) - 10 - ALTV248220 Series...
- Page 11 3.5” (88.9mm) (88.9mm) 12” (304.8mm) 12” (304.8mm) 2.5” (63.5mm) 5.88” (149.35mm) 3.5” (88.9mm) 1.13” 1” (28.7mm) (25.4mm) 7.5” 4.5” 4.5” (190.5mm) (114.3mm) (114.3mm) 4.5” (114.3mm) 1” 1” (25.4mm) (25.4mm) 5.75” 0.88” 0.88” (146.05mm) (22.35mm) (22.35mm) ALTV248220 Series - 11 -...
- Page 12 (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIALTV248220 Series E08R...
