ALTV248 Series
CCTV Power Supplies
Installation Guide
Models Include:
• ALTV248
- 24VAC @ 4 amp (100VA).
- Eight (8) Fuse Protected Outputs.
• ALTV248175
- 24VAC @ 7.25 amp (175VA).
or 28VAC @ 6.25 amp (175VA).
- Eight (8) Fuse Protected Outputs.
• ALTV248300
- 24VAC @ 14 amp (350VA)
or 28VAC @ 12.5 amp (350VA).
- Eight (8) Fuse Protected Outputs.
• ALTV248300M
- 24VAC @ 12.5 amp (300VA)
or 28VAC @ 10.5 amp (300VA).
- Eight (8) Fuse Protected Outputs.
• ALTV248600
- 24VAC @ 28 amp (700VA)
or 28VAC @ 25 amp (700VA).
- Eight (8) Fuse Protected Outputs.
• ALTV248CB
- 24VAC @ 4 amp (100VA).
- Eight (8) PTC Protected Outputs.
• ALTV248175CB
- 24VAC @ 7.25 amp (175VA).
or 28VAC @ 6.25 amp (175VA).
- Eight (8) PTC Protected Outputs.
• ALTV248300CB
- 24VAC @ 14 amp (350VA)
or 28VAC @ 12.5 amp (350VA).
- Eight (8) PTC Protected Outputs.
• ALTV248300CBM
- 24VAC @ 12.5 amp (300VA)
or 28VAC @ 10.5 amp (300VA).
- Eight (8) PTC Protected Outputs.
• ALTV248600CB
- 24VAC @ 28 amp (700VA)
or 28VAC @ 25 amp (700VA).
- Eight (8) PTC Protected Outputs.
R e v. 040904
Advertisement
Related Manuals for Altronix ALTV248
Summary of Contents for Altronix ALTV248
-
Page 1: Installation Guide
ALTV248 Series CCTV Power Supplies Installation Guide Models Include: • ALTV248 • ALTV248CB - 24VAC @ 4 amp (100VA). - 24VAC @ 4 amp (100VA). - Eight (8) Fuse Protected Outputs. - Eight (8) PTC Protected Outputs. • ALTV248175 • ALTV248175CB - 24VAC @ 7.25 amp (175VA). - Page 2 Overview: These Altronix CCTV Power Supplies provide 24VAC (some models supply 24VAC or 28VAC) distributed via eight (8) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. Eight (8) Output ALTV248 Reference Chart: Altronix Model Number...
- Page 3 Installation Instructions: 1. Mount unit in desired location. 2. Slide switch on PD board to OFF position for models ALTV248 and ALTV248CB (Figs. 1 & 2, pg. 4). Turn OFF main switch on all other models, (Figs. 3-5, pgs. 5-6).
- Page 4 Fig. 1 - ALTV248 • ALTV248CB Terminal Blocks for Fig. 1 Back Panel of Enclosure Fig. 2 - ALTV248175 • ALTV248175CB Terminal Blocks for Fig. 2 - 4 -...
- Page 5 Fig. 3 ALTV248300 • ALTV248300CB Terminal Blocks for Fig. 3 Fig. 4 - ALTV248300M • ALTV248300CBM Terminal Blocks for Fig. 4 - 5 -...
- Page 6 Fig. 5 - ALTV248600 • ALTV248600CB Terminal Blocks for Fig. 5 - 6 -...
- Page 7 Enclosure Dimensions for: • ALTV248 • ALTV248CB • ALTV248175 • ALTV248175CB • ALTV248300M • ALTV248300CBM 8.5"H x 7.5"W x 3.5"D - 7 -...
- Page 8 13"H x 13.5"W x 3.5"D Altronix is not responsible for any typographical errors. Altronix Corp. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. II1ALTV248Series D19D MEMBER - 8 -...
