UL Listed Isolated Series
CCTV Power Supplies
Models Include:
ALTV248ULHi
- 24VAC @ 12.5A total output.
- Eight (8) 1.56A Fuse Protected
Isolated Outputs.
ALTV248ULMi
- 24VAC @ 12.5A total output.
- Eight (8) 1.56A Fuse Protected
Isolated Outputs.
ALTV2416ULi
- 24VAC @ 25A total output.
- Sixteen (16) 1.56A Fuse Protected
Isolated Outputs.
For models with factory installed 3-wire line cord add suffix "3" (e.g. ALTV248ULHi3).
Installation Guide
Rev. 113004
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
ALTV248ULCBHi
- 24VAC @ 12.5A total output.
- Eight (8) 1.56A PTC Protected
Isolated Outputs.
ALTV248ULCBMi
- 24VAC @ 12.5A total output.
- Eight (8) 1.56A PTC Protected
Isolated Outputs.
ALTV2416ULCBi
- 24VAC @ 25A total output.
- Sixteen (16) 1.56A PTC Protected
Isolated Outputs.
More than just power.
TM
Advertisement
Related Manuals for Altronix ALTV248ULHi
Summary of Contents for Altronix ALTV248ULHi
- Page 1 UL Listed Isolated Series CCTV Power Supplies Models Include: ALTV248ULHi ALTV248ULCBHi - 24VAC @ 12.5A total output. - 24VAC @ 12.5A total output. - Eight (8) 1.56A Fuse Protected - Eight (8) 1.56A PTC Protected Isolated Outputs. Isolated Outputs. ALTV248ULMi ALTV248ULCBMi - 24VAC @ 12.5A total output.
-
Page 2: Specifications
Overview: Altronix Isolated CCTV Power Supplies provide 24VAC distributed via eight (8) or sixteen (16) fuse or PTC protected isolated outputs for powering CCTV cameras, heaters, and other video accessories. Isolated Power Supply Reference Chart: Altronix Model Number ALTV248ULHi 24VAC 12.5A –... -
Page 3: Terminal Identification
6. Connect CCTV cameras to output terminals using the following procedure: Camera 1 to output 1A & 1B. Camera 5 to output 5A & 5B. Camera 2 to output 2A & 2B. Camera 6 to output 6A & 6B. Camera 3 to output 3A & 3B. Camera 7 to output 7A &... - Page 4 Fig. 1 - ALTV248ULHi and ALTV248ULCBHi Used on ALTV248ULCBHi Class 2 power-limited PD8I ISOLATED POWER DISTRIBUTING BOARD non power- limited PD8I ISOLATED POWER DISTRIBUTING BOARD Illuminated Power Disconnect Circuit Breaker with manual reset White Lead Input 115VAC, 50/60Hz Green Lead...
- Page 5 Fig. 2 - ALTV248ULMi and ALTV248ULCBMi Illuminated Power Disconnect Circuit Breaker with manual reset Input 115VAC, 50/60Hz non power- Transformer limited underneath power PD8I distribution ISOLATED POWER DISTRIBUTING BOARD board Class 2 power-limited PD8I ISOLATED POWER DISTRIBUTING BOARD Used on ALTV248ULCBMi UL Listed Isolated Series Installation Guide - 5 -...
- Page 6 Fig. 3 - ALTV2416ULi and ALTV2416ULCBi Used on ALTV2416ULCBi Class 2 power-limited PD8I ISOLATED POWER DISTRIBUTING BOARD non power- non power- limited limited PD8I PD8I ISOLATED POWER ISOLATED POWER DISTRIBUTING BOARD DISTRIBUTING BOARD Green Lead (ground) Input 115VAC, 50/60Hz Illuminated Power Disconnect Circuit Breaker with manual reset - 6 - UL Listed Isolated Series Installation Guide...
- Page 7 Enclosure Dimensions (H x W x D) for: • ALTV248ULMi • ALTV248ULCBMi 8.5” x 7.5” x 3.875” (215.9mm x 191mm x 98.4mm) 3.63” (92.2mm) 1.25” (31.75mm) 7.25” (184.15mm) 0.6” (15.24mm) 0.6” (15.24mm) 1.25” (31.75mm) 1.25” (31.75mm) 1.25” (31.75mm) 0.6” (15.24mm) 0.6” (15.24mm) 3.85”...
- Page 8 1.0” 1.0” 10.5” (266.7mm) (25.4mm) (25.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIULisolated Series L03U...
