Altronix ALTV248 Series Installation Manual
Cctv power supplies
Hide thumbs
Also See for ALTV248 Series:
- Installation manual (8 pages) ,
- Installation manual (12 pages) ,
- Installation manual (12 pages)
Advertisement
Quick Links
ALTV248 Series
CCTV Power Supplies
Installation Guide
Models Include:
ALTV248
- 24VAC @ 4A (100VA) or
28VAC @ 3.5A.
- Eight (8) Fuse Protected Outputs.
ALTV248175
- 24VAC @ 7.25A (175VA) or
28VAC @ 6.25A (175VA).
- Eight (8) Fuse Protected Outputs.
ALTV248300
- 24VAC @ 14A (350VA) or
28VAC @ 12.5A (350VA).
- Eight (8) Fuse Protected Outputs.
ALTV248300M
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (300VA).
- Eight (8) Fuse Protected Outputs.
ALTV248600
- 24VAC @ 28A (700VA) or
28VAC @ 25A (700VA).
- Eight (8) Fuse Protected Outputs.
Rev. 070612
All manuals and user guides at all-guides.com
ALTV248CB
ALTV248175CB
ALTV248300CB
ALTV248300CBM
ALTV248600CB
- 24VAC @ 4A (100VA) or
28VAC @ 3.5A.
- Eight (8) PTC Protected Outputs.
- 24VAC @ 7.25A (175VA) or
28VAC @ 6.25A (175VA).
- Eight (8) PTC Protected Outputs.
- 24VAC @ 14A (350VA) or
28VAC @ 12.5A (350VA).
- Eight (8) PTC Protected Outputs.
- 24VAC @ 12.5A (300VA) or
28VAC @ 10A (300VA).
- Eight (8) PTC Protected Outputs.
- 24VAC @ 28A (700VA) or
28VAC @ 25A (700VA).
- Eight (8) PTC Protected Outputs.
More than just power.
TM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix ALTV248 Series
Summary of Contents for Altronix ALTV248 Series
- Page 1 All manuals and user guides at all-guides.com ALTV248 Series CCTV Power Supplies Installation Guide Models Include: ALTV248 ALTV248CB - 24VAC @ 4A (100VA) or - 24VAC @ 4A (100VA) or 28VAC @ 3.5A. 28VAC @ 3.5A. - Eight (8) Fuse Protected Outputs.
-
Page 2: Specifications
All manuals and user guides at all-guides.com Overview: Altronix ALTV248 Series CCTV Power Supplies provide 24VAC or 28VAC distributed via eight (8) fuse or PTC protected outputs for powering CCTV cameras, heaters and other video accessories. Eight (8) Output ALTV248 Reference Chart:... -
Page 3: Installation Instructions
(servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. ALTV248 Series - 3 -... - Page 4 COMMON POWER OUTPUTS used on ALTV248CB Input 115VAC, 50/60Hz, 0.9A Voltage Selection Terminal Blocks for Fig. 1 Configuration 24VAC Output (Yellow) (Black) 24VAC or 28VAC fused or PTC 28VAC protected outputs 1 through 8. Output (Black) (Yellow) - 4 - ALTV248 Series...
- Page 5 ALTV248175CB Illuminated Power Switch Input 115VAC, 50/60Hz, 1.45A Voltage Selection Terminal Blocks for Fig. 2 Configuration 24VAC Output (Yellow) (Black) 24VAC or 28VAC fused or PTC 28VAC protected outputs 1 through 8. Output (Black) (Yellow) ALTV248 Series - 5 -...
- Page 6 COMMON POWER OUTPUTS Illuminated Power Switch Input 115VAC, 50/60Hz, 2.7A Voltage Selection Terminal Blocks for Fig. 3 Configuration 24VAC Output (Yellow) (Black) 24VAC or 28VAC fused or PTC 28VAC protected outputs 1 through 8. Output (Black) (Yellow) - 6 - ALTV248 Series...
- Page 7 Power Switch Input 115VAC, used on 50/60Hz, 2.7A ALTV248300CBM Voltage Selection Terminal Blocks for Fig. 4 Configuration 24VAC Output (Yellow) (Black) 24VAC or 28VAC fused or PTC 28VAC protected outputs 1 through 8. Output (Black) (Yellow) ALTV248 Series - 7 -...
- Page 8 MAIN FUSE Illuminated Power Switch Input 115VAC, 50/60Hz Voltage Selection Terminal Blocks for Fig. 5 Configuration 24VAC Output (Yellow) (Black) 24VAC or 28VAC fused or PTC protected outputs 1 through 4. 28VAC Output (Black) (Yellow) - 8 - ALTV248 Series...
- Page 9 (15.24mm) (31.75mm) (153.67mm) 1.125” 1.125” (28.575mm) (28.575mm) 2” (50.8mm) 2” (50.8mm) 8.125” (206.375mm) 1” 1” (25.4mm) (25.4mm) 6.05” 0.6” 0.6” 1.25” (153.67mm) (15.24mm) (15.24mm) (31.75mm) 3.5” (88.9mm) 1” (25.4mm) 1” 5.25” 1” (25.4mm) (133.35mm) (25.4mm) ALTV248 Series - 9 -...
- Page 10 1” (25.4mm) (25.4mm) 0.9” 0.9” (22.86mm) (22.86mm) 8.13” 8.13” (206.5mm) (206.5mm) 1.75” (44.45mm) 1” 1” (25.4mm) (25.4mm) 0.6” 1.25” 0.6” (15.24mm) (31.75mm) (15.24mm) 3.85” (97.79mm) 3.85” (97.79mm) 1” (25.4mm) 1” 1” (25.4mm) (25.4mm) 7.25” (184.15mm) - 10 - ALTV248 Series...
- Page 11 3.5” (88.9mm) (88.9mm) 12” (304.8mm) 12” (304.8mm) 2.5” (63.5mm) 5.88” (149.35mm) 3.5” (88.9mm) 1.13” 1” (28.7mm) (25.4mm) 7.5” 4.5” 4.5” (190.5mm) (114.3mm) (114.3mm) 4.5” (114.3mm) 1” 1” (25.4mm) (25.4mm) 5.75” 0.88” 0.88” (146.05mm) (22.35mm) (22.35mm) ALTV248 Series - 11 -...
- Page 12 (267mm) (25mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIALTV248 Series B23R...
