117 Channels mode
CH Function value
1 Pan movement 0-255
0-55
Unlimited Pan
2 56-155
movement
156-255
3 Pan fine 0-255
4 Tilt 0-255
0-55
Unlimited Tilt
5 56-155
movement
156-255
6 Tilt fine 0-255
7 Pan/Tilt speed 0-255
8 Dimmer 0-255
0-3
4-95
9 Strobe
96-176
177-255
10 R1 dimmer 0-255
11 G1 dimmer 0-255
12 B1 dimmer 0-255
13 W1 dimmer 0-255
...... ...... ......
...... ...... ......
106 R25 dimmer 0-255
107 G25 dimmer 0-255
108 B25 dimmer 0-255
109 W25 dimmer 0-255
Effect show of
0-89
110 numbers and 90-233
punctuations 234-235
Effect show of
0-234
111
letters 234-235
Effect show of
0-234
112
static gobos 234-235
113 Color of letters 0-255
Dynamic gobos 0-234
114
show 234-235
115 Speed of effects 0-255
0-49
50-74
75-99
116 Macro Function
100-124
125-149
150-199
200-255
0-250
117 Reset
251-255
Details
0~540 degree
Tilt non movement
Pan unlimited clockwise rotate slow to fast
Pan unlimited reversely rotate slow to fast
16 bit Pan fine adjustment
0~270 degree
Pan non movement
Tilt unlimited clockwise rotate slow to fast
Tilt unlimited reversely rotate slow to fast
16 bit Tilt fine adjustment
From fast to slow
Linear dimmer from dark to bright
No function
Strobe with the same step from slow to fast
Random strobe
Thunder strobe
LED 1 Red dimmer from dark to bright
LED 1 Green dimmer from dark to bright
LED 1 Blue dimmer from dark to bright
LED 2 white dimmer from dark to brigh
......
......
LED 25 Red dimmer from dark to bright
LED 25 Green dimmer from dark to bright
LED 25 Blue dimmer from dark to bright
LED 25 white dimmer from dark to bright
Effect show of numbers from 0 to 9
Effect show of punctuations
Running water effect
Effect show of letters from A to Z
Running water effect
Effect show of static gobos
Running water effect
Color choice for the letters
Effect show of dynamic gobos
Running water effect
From fast to slow
No function
Numbers and punctuations show(Against CH
12)
Letters show(Operate against CH 13)
Static gobos show(Operate against CH 14)
Dynamic gobos show(Operate against CH 16)
Auto Run
Sound activated
No function
Reset within 3 seconds
.9.

2. Safety Instructions

This device has left the factory in perfect condition. In order to maintain this condition and to ensure
a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning
notes written in this user manual.
If the device has been exposed to temperature changes due to environmental changes, do not
switch it on immediately. The arising condensation could damage the device. Leave the device
switched off until it has reached room temperature.
This device falls under protection-class I. Therefore it is essential that the device be earthed.
The electric connection must carry out by qualified person.
The device shall only be used with rate voltage and frequency.
Make sure that the available voltage is not higher than stated at the end of this manual.
Make sure the power cord is never crimped or damaged by sharp edges. If this would be the
case, replacement of the cable must be done by an authorized dealer.
Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
During initial start-up some smoke or smell may arise. This is a normal process and does
not necessarily mean that the device is defective, it should decrease gradually. Please don't
project the beam onto combustible substances.
Fixtures cannot be installed on combustible substances, keep more than 50cm distance with wall
for smooth air flow, so there should be no shelter for fans and ventilation for heat radiation.
If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by
the manufacturer or his service agent or a similar qualified person in order to avoid a hazard.
.2.
