Never stand directly below the device when mounting, removing, or servicing the fixture from a
periodic safety inspection of all installation material and the fixture. If you lack these qualifications, do
not attempt the installation yourself. Improper installation can result in bodily injury.
Be sure to complete all rigging and installation procedures before connecting the main power cord to
the appropriate wall outlet.
Clamp Mounting: The LED Matrix moving head provides a unique mounting bracket assembly that
integrates the bottom of the base, the included "Omega Bracket," and the safety cable rigging point in
one unit (see the illustration below). When mounting this fixture to truss be sure to secure an
appropriately rated clamp to the included omega bracket using a M10 screw fitted through the center
hole of the "omega bracket". As an added safety measure be sure to attached at least one properly
rated safety cable to the fixture using on of the safety cable rigging point integrated in the base
assembly
Regardless of the rigging option you choose for our Matrix moving head , always be sure to secure
your fixture with a safety cable. The fixture provides a built-in rigging point for a safety cable on the
hanging bracket as illustrated above. Be sure to only use the designated rigging point for the safety
cable and never secure a safety cable to a carrying handle.
.5.

6. Menu Operations

Button instruction:

MENU UP DOWN
Operate instruction details
ENTER
