Final Connections And Installation - Dynojet Power Commander III Installation Instructions

PCIII connector
PCIII harness
Ground wire
from PCIII
i735-411 www.powercommander.com
Stock connector
Grey wire
12 Plug the ORANGE colored wires
from the PCIII in-line of the front
injector and stock wiring harness
(Fig. H).
13 Remove the right hand fairing.
14 Route the PCIII harness along the
right hand side frame down tube.
the existing wraps to hold the PCIII
harness in place (Fig. J).
15 Locate the Throttle Position Sensor on
the right hand side of the throttle bod-
ies.
16 Crimp the supplied wire tap to the
ORANGE wire (C position).
TPS
17 Connect the GREY wire from the
PCIII to the wire tap.
It is recommended to use dielectric
grease on these connections.
18 Attach the ground wire from the PCIII
to the right hand engine cover bolt
shown in Figure K
19 Reinstall the right hand fairing
2008 Ducati 848 - PCIII USB - 4
