CYP CPLUS-V8H8HP Operation Manual page 28

Command Name
GET OUT x HDCP
ABILITY n
GET IN x HDCP
ABILITY n
SET PATTERN x
MODE b
GET PATTERN x
MODE b
SET PATTERN x
TIMING n
GET PATTERN x
TIMING n
GET PATTERN
TIMING LIST
SET PATTERN x TYPE
n
Command Name
SET PATTERN x TYPE
n
23
Description
Print output[x] sink
HDCP ability to the
screen
Print input n source
HDCP ability to the
screen
set pattern mode
on, off
get pattern mode on,
off
set pattern output
timing
get pattern output
timing
get support pattern
output timing list
set pattern
output type
Description
get pattern output
type
Description of parameter
x = a,b,c...h
n2 = 0,1,2 (0-
None HDCP, 1-
HDCP1.x, 2-
HDCP2.2)
n1 = 1,2,3...8
n2 = 0,1,2,3 (0-None
HDCP, 1-HDCP1.x, 2-
HDCP2.2, 3-
HDCP1.4+2.2)
x = a,b,c,d,e...h
b = on, off
x = a,b,c,d,e...h
b = on, off
x = a,b,c...h(HDMI out,
HDBT out, LR out... )
n =
1~41,401~435,501~506,..
x =
a,b,c...h(HDMI
out, HDBT out,
LR out... )
n =
1~41,401~435,5
01~506,...
Please refer "timing
code" table for detail
timing value definitions.
x = a,b,c,d,e...h
n = 1: black, 2:
white, 3: red, 4:
green, 5: blue,
6: magenta, 7:
ll 8
Description of parameter
x = a,b,c,d,e...h
n = 1: black, 2: white,
3: red, 4: green, 5:
blue, 6: magenta, 7:
yellow, 8: cyan, 9:
gray
