CYP CPLUS-V8H8HP Operation Manual page 18

Command Name
SET OUT X NAME S
GET OUT x NAME
SET OUT x ROUTE N Set output routing
GET IN NAME LIST
GET OUT NAME LIST
SET OUT X 4K2K
DOWNSCALE
MODE N
GET OUT X HDCP
4K2K DOWNSCALE
MODE N
GET IN N1 HACTIVE
N2
GET IN N1 VACTIVE
N2
GET IN N1 REFRESH
RATE
13
Description
Name an output sync
monitor
Print the output
name to the screen
Print all input
name to the
screen
Print all output
name to the
screen
Config output x
4K2K downscale
mode for sync
monitor
Print output x 4K2K
downscale mode to
the screen
Print input Hactive to
the screen
Print input Vactive to
the screen
Print input refresh
rate to the screen
Description of parameter
x = a,b,c ...h
s= name string
name size : 32 Byte
x = a,b,c ...h
x=a,b,c,d,e...h
n=1,2,3,4,5...8
NONE
NONE
x = a,b,c...h
n = 0-passthrough, 1-
auto, 2-1080p
x = a,b,c...h
n = 0-passthrough, 1-
auto, 2-1080p
n1 = 1,2,3...8
n2 = 640,800,1024
n1 = 1,2,3...8
n2 = 480,768,600
n1 = 1,2,3...8
n2 =
5994,6000,7500,
8503,
