SPECIFICATIONS

2.1 Input Signal

Table 1: Input Signal
Power Supply
Input Signal Range
Compliance Voltage
Effective Resistance
Minimum Required
Operating Current
Maximum Shut-down
Current
Power Interruption
Time Limit
Power-up time
Communications

2.2 Pneumatic Output

Table 2: Pneumatic Output
Output Pressure
0 to 100% of air supply pressure.
Range
Single Acting Relay –
9.06 Nm³/h @ 1.5 bar
(5.33 SCFM @ 22 PSI)
20.8 Nm³/h @ 4.1 bar
(12.2 SCFM @ 60 PSI)
Output Air Capacity
Double Acting Relay –
14.3 Nm³/h @ 1.5 bar
(8.44 SCFM @ 22 PSI)
30.6 Nm³/h @ 4.1 bar
(18.0 SCFM @ 60 PSI)
Primary Output Ports
(Port is pressurized in
Single Acting Relay – Port B
energized state. Port
Double Acting Relay – Port A
is exhausted upon
loss of power.)
10
Logix
Positioner Alone or with Multi-Function Card
Two-wire, 4-20 mA
10.0 VDC plus line losses (Logix 520MD+)
6.0 VDC plus line losses (Logix 510+)
4 - 20 mA (HART)
10.0 VDC @ 20 mA (Logix 520MD+)
6.0 VDC @ 20 mA (Logix 510+)
500 Ω @ 20 mA (Logix 520MD+) Typical
300 Ω @ 20 mA (Logix 510+) Typical
3.8 mA
3.6 mA
After power has been applied for at least 10
seconds, a 60 ms power interruption will not
cause the positioner to reset.
Time from application of power to begin con-
trolling valve < 1.0 second.
HART protocol
520MD+ and 510+ Digital Positioners FCD LGENIM0105-15-AQ – 05/16
®

2.3 Air Supply

Table 3: Air Supply
Minimum Input Pressure
Maximum Input Pressure
Air Supply Quality
Operating Humidity
Acceptable Supply Gasses
Air Consumption
2.4 Analog Output – Multi-Function Card
Table 4: 4 to 20 mA Analog Output Specification
NOTE: For entity parameters, see section 3 HAZARDOUS AREA
CERTIFICATIONS.
Power Supply Range
Current Signal Output
Linearity
Repeatability
Hysteresis
Operating Temperature
1.5 Bar (22 PSI)
Single Acting Relay – 6.2 Bar (90 PSI)
Double Acting Relay – 10.3 Bar (150 PSI)
The air supply must be free from moisture,
oil and dust by conforming to the ISA 7.0.01
standard. (A dew point at least 18 degrees
Fahrenheit below ambient temperature,
particle size below five microns—one
micron recommended—and oil content not
to exceed one part per million).
0 - 100% non-condensing
Air, sweet natural gas, nitrogen and CO2
are acceptable supply gasses. Sour natural
gas is not acceptable. For Type nA and Type
tb installation only air or inert gas may be
connected to the air supply inlet.
Single Acting Relay –
0.069 Nm³/h @ 1.5 bar
(0.041 SCFM @ 22 PSI)
0.082 Nm³/h @ 4.1 bar
(0.050 SCFM @ 60 PSI)
Double Acting Relay –
0.297 Nm³/h @ 1.5 bar
(0.175 SCFM @ 22 PSI)
0.637 Nm³/h @ 4.1 bar
(0.375 SCFM @ 60 PSI)
10.0 to 40 VDC, (24 VDC Typical)
4 to 20 mA
1.0% F.S.
0.25% F.S.
1.0% F.S.
-52 to 85°C (-61.6 to 185°F)
