4 Logix 3200MD
Positioner Overview
The Logix 3200MD digital positioner is a two-wire 4-20 mA input digital
valve positioner. The positioner is configurable through the local user
interface. The Logix 3200MD utilizes the HART protocol to allow two-
way remote communications with the positioner. The Logix 3200MD
positioner can control both double- and single-acting actuators with
linear or rotary mountings. The positioner is completely powered by
the 4-20 mA input signal. Start up current must be at least 3.6 mA
without AO card or 3.85 mA with AO card.
4.1

Specifications

Table I: Electrical Specifications
Power Supply
Compliance Voltage
Effective Resistance
Communications
Minimum Operating
Current
Maximum Voltage
Table II: ValveSight Suite Software Specifications
Minimum Pentium processor running Windows 95, 98,
NT, 2000, XP, 32 MB total memory (64 MB recom-
Computer
mended), 30 MB available hard disk space, CD-ROM
drive
Ports 1 minimum available with 8 maximum possible. (Can
also communicate via PCMCIA and USB connections)
HART Modem RS-232/PCMCIA card/USB
May be required in conjunction with some DCS
HART Filter
hardware
HART MUX MTL 4840/ELCON 2700
4
User instructions - Digital Positioner 3200MD LGENIM0059-01 10/08
®
Two-wire, 4-20 mA
10.0 to 30.0 VDC
10.0 VDC @ 20 mA
495 Ω @ 20 mA Typical
Add 20 Ω when HART communication active
HART Protocol
3.6 mA without AO board
3.85 mA with AO board
30.0 VDC
Table III: Environmental Conditions
Standard
Operating Temperature Range
Low
Transport and Storage
-40° to 176°F (-40° to 80°C)
Temperature Range
Operating Humidity 0 - 100% non-condensing
Note: The air supply must conform to ISA Standard ISA 7.0.01 (a dew
point at least 18 degrees Fahrenheit below ambient temperature, particle
size below five microns—one micron recommended—and oil content not
to exceed one part per million).
Table IV: Physical Specifications
Housing Material Cast, powder-painted aluminum, stainless steel
Soft Goods Buna-N / Florosilicone
8.3 pounds (3.9 kg) aluminum
Weight
20.5 pounds (9.3 kg) stainless steel
Table V: Positioner Specifications
Deadband <0.1% full scale
Repeatability <0.05% full scale
Linearity <0.5% (rotary), <0.8%, (sliding stem) full scale
Air Consumption <0.3 SCFM (0.5 Nm
Air Capacity 12 SCFM @ 60 psi (4 barg) (0.27 Cv)
Table VI: 4 to 20 mA Analog Output Specifications
Potential Range of Rotation
Power Supply Range
Maximum Load Resistance (ohms)
Current Signal Output
Linearity
Repeatability
Hysteresis
Operating Temperature
-4° to 176°F
(-20° to 80°C)
-40° to 176°F
(-40° to 80°C)
/hr) @ 60 psi (4 barg)
3
40° - 95°
12.5 to 40 VDC, (24 VDC typical)
(Supply voltage - 12.5) / 0.02
4-20 mA
1.0% F.S.
0.25% F.S.
1.0% F.S.
-40° to 176°F, -40° to 80°C
