Datapath VSN400 User Manual page 54

-id
-window -w
-closewindows -cw
-closewindow -c
-provider -pr
-windowstyle -ws
-input -in
-savelayout -sl
-layout -ol
-schedule -s
Impersonation Commands
Short
Long Switch
Switch
-username -un
-password -pwd
Advanced Users
-id=number
When a window is created it can be allocated in ID. To modify or close a window,
specify its ID so the correct window is addressed. Only one window can exist on the
wall at any time with the allocated ID.
-window=[top],[left],[width],[height]
Set the position and size of the window.
Commas must be used between values.
Must be used in conjunction with the –id switch. To display a Vision window a typical
command line argument would be:
wcmd –machine=10.0.0.21:8099–id=3–provider=Capture–input=3–win-
dow=200,300,500,500
Closes all open windows.
Used with a specific ID will close that window.
-provider={Capture|Video|Word|Application|Quant|Image|IPDecode|Web|Pd-
f|Remote}Target a type of provider on the server.
The types of Provider that may be available are: Images, Vision, MS Word, IP, Inter-
net, VNC, Quant, Applications and PDF providers.
-windowstyle={BorderAndTitlebar|NoBorderAndTitlebar}
Sets the style of the window.
-input=name
The name of the input to target on the server.
The name of the input will depend on the type of provider being used. For exam-
ple, if the input you are selecting is from the Capture then the input name will be
a number from 1 upwards. For other Providers (IP) it will be a friendly name. If the
input comes from the Video then the full path is required. See Example Command 2
below.
-savelayout=name
Allows you to save the current wall view as a layout. If the layout name contains
spaces then enclose the name in quotes, for example:
-savelayout="Layout One"
-layout=layout file
Open a specific layout file. If the layout name contains spaces then enclose the name
in quotes, for example:
-layout="CCTV One"
Used in conjunction with the –layout command to create a scheduled task to exe-
cute a specific layout. This creates a single scheduled task:
wcmd –machine=10.0.0.21:8099–layout="my layout" –scheduled="15/05/2017
09:00:00"
If you are trying to connect to a machine other than the one you are using a user-
name and password may be required:
-username="user name"
-password=password
Description/Example
54
Advanced Users
