Chapter 12 - Advanced Users

This chapter is aimed towards advanced users and covers the following:
WallControl 10 Command Line Interface
•
Software Development Kit (SDK)
•
RAID
•
ImageDP4+ Video BIOS
•
Replacing Cards
•
Updating Firmware
•
System Recovery
•

12.1 Command Line Interface

12.1.1
WallControl 10
The WallControl 10 command line interface can be accessed from a command prompt and also by using Telnet for
issuing commands remotely, specifying wcmd.exe.
Telnet
If you intend using a Telnet connection, the following procedures should be followed prior to using the Telnet Client:
1. Run the WallControl 10 Telnet Server:
C:\Program Files (x86)\WallControl 10\Telnet Server\WallControl 10 Telnet Server.exe (double click on the .exe file)
This will start the WallControl 10 Telnet Server and ensures it runs continually after the machine is rebooted.
2. Switch on the Telnet Client:
Control Panel/Programs and Features/Turn Windows features on or off.
Ensure the Telnet Client checkbox is selected.
3. Type "telnet" into the command prompt followed by the name of the machine you wish to connect to, by default
Telnet is accessible on port 23, if you have it configured for something different then you will need to specify the port
number to connect on. If the machine name contains spaces then enclose the name in quotes, for example:
telnet 127.0.0.1
or
telnet 127.0.0.1 23
Command Line Arguments
The command line arguments are grouped into three categories:
Information
•
Action
•
Impersonation
•
