Chapter 3 - General

3.1 Overview

Datapath's VSN400 systems are high quality, flexible solutions for smaller, more compact video wall and multi-screen
display applications. The systems have been developed for installations that require a balanced number of HD video
captures and HD video outputs and optimised to operate with the latest generation of our world leading PCI Express
graphics and video capture cards, providing flexible solutions throughout the professional AV industry.
Each system has been designed for use in demanding environments. Each component has been subjected to rigorous
testing to ensure the highest levels of performance and reliability.
In summary:
High performance and reliability in demanding conditions
•
Suited for 24/7 applications
•
Can be operated via a network
•
WallControl 10 software (optional) - Display video on the desktop in real time using an array of features
•
Wall Monitor software (optional) - Provides monitoring of the temperature and voltage sensors on system
•
components

3.2 Associated Output/Input Cards and Related Products

The following table lists the range of Datapath cards associated with the VSN400 range of video wall controllers:
Product
ImageDP4+
ActiveSQX
VisionHD2-SQX
VisionSC-DP2
VisionSC-SDI4
VisionSC-HD4+
VisionAV-HD
VisionAV-SDI
VisionHD4
VisionRGB-E1s
VisionAV
VisionRGB-E2s
VisionDVI-DL
VisionSD4+1s
VisionSDI2
VisionSD8
We are constantly updating our product portfolio, for the latest details on our full product range please visit our
website:
www.datapath.co.uk

3.3 Product Datasheets

Product datasheets are available to download from
General
Quad output DisplayPort graphics card.
Dedicated IP Streaming decoding card.
Triple channel capture and IP Streaming encoding card
Dual channel, 4K UHD DisplayPort capture card.
Four channel 3G-SDI video capture card.
Quad HDMI video capture card.
Four lane PCI Express capture card with 2 x HD DVI-I and 1 SD channels.
Four lane PCI Express capture card with 1 x HD DVI-I, SD, SDI channels.
Eight lane PCI Express capture card with four independent DVI-I HD channels.
Single channel HD video capture card.
Single Channel HD and single channel SD video capture card.
Dual channel HD video capture card.
Single channel Dual-Link video capture card.
Video capture card with four channels of SD and one of HD.
Dual channel HD-SDI video capture card.
Eight channel SD video capture card.
Description
