The WallControl 10 - Security Administration Client (Only Available with WallControl 10 Pro)
Start | All Programs | WallControl 10 - Security Administration Client
The WallControl 10 - Security Administration Client allows Administrators to assign specific users to roles on a wall by
wall basis. For example, a User can be assigned a role allowing unrestricted access on one wall but assigned a role on
another wall which only allows the opening of pre-determined layouts.
Prior to the Security Client being used for the first time, the SecurityOnOff.exe program must be run to enable security
protection for the application. To run the SecurityOnOff.exe, ensure you are logged into Windows with
Administrator Rights.
Locate and double click on the SecurityOnOff.exe file:
Program Files\WallControl 10\ Security Server\SecurityOnOff
A WallControl 10-Pro serial dongle must be inserted into a vacant USB port. If the dongle is removed or swapped, the
Security Client will not open and an error message is displayed, therefore it is important the dongle is not removed.
The WallControl 10 Security Application help file contains information on how to:
Import users from the Windows Active Directory into the database.
•
Create and edit roles.
•
Assign permissions to providers, layouts and sources giving specific roles access to them.
•
Assign roles to walls.
•
