Wall Controller
Quick Start Guide
VSN400 Series of Wall Controllers
Thank you for purchasing the Datapath VSN400 Wall Controller. The aim of this
document is to quickly guide you through the process of initial setup. For detailed
instructions consult the system User Guide which can be found on the Recovery
Media.
www.datapath.co.uk | sales@datapath.co.uk | +44 (0) 1332 294441

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSN400 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Datapath VSN400 Series

Summary of Contents for Datapath VSN400 Series

  • Page 1 Quick Start Guide VSN400 Series of Wall Controllers Thank you for purchasing the Datapath VSN400 Wall Controller. The aim of this document is to quickly guide you through the process of initial setup. For detailed instructions consult the system User Guide which can be found on the Recovery Media.

  • Page 2: Step 2 Keyboard And Mouse

    PCIe card product leaflets Cables/Adapters as specified in the product leaflets Each Datapath system is custom built therefore the number and type of input and output cards will differ from system to system. Accompanying this Quick Start Guide are PCIe card product leaflets which give details on how the cards are installed and any accessories supplied with them.

  • Page 3: Step 3 Connect To A Network (Optional)

    STEP 3 CONNECT TO A NETWORK (OPTIONAL) Network Cable not supplied. STEP 4 CONNECT INPUT SOURCE Each Datapath system is custom built. The number and type of inputs will differ from system to system. Contained within the documentation pack are PCIe card product leaflets which give details on how the cards are connected.

  • Page 4: Step 6 Powering Up The System

    STEP 5 CONNECT AN INPUT SOURCE To enable you to complete the initial setup of the system, displays must be connect- ed to the first and second output as shown below. STEP 6 POWERING UP THE SYSTEM ATX System RPSU System Connect power cables then plug into a mains supply.

  • Page 5: Step 7 Windows 10 Setup

    Switch on the system. STEP 7 WINDOWS 10 SETUP Once the system has been configured in our factory the operating system is resealed, meaning that when switching on the system for the first time the operating system setup commences. You will be prompted to enter information to set up your wall controller. There is no requirement for users to activate Windows 10, activation is done automatically.

  • Page 6: Step 8 Display Configuration

    STEP 8 DISPLAY CONFIGURATION Once the Windows setup is complete, the Display Driver Configuration Tool (DDCT) is displayed. The DDCT will guide you, step by step, through the configuration of the graphics outputs, enabling you to quickly create one or more video walls On the final stage of the configuration, the (DDCT) will recommend the optimum way to connect your VSN400 to your video wall displays.
  • Page 7 Start | All Programs | WallControl 10 - Client The WallControl 10 - Client Indicates the server you are connected too. 2 A representation of the display wall associated with the server. Sources Tab - Displaying all the sources connected to the server for use on your display wall.
  • Page 8 Display Wall Display Wall Sources When opened, the display wall tab shows a live representation of the physical wall and the sources available to display on it. To place a source on the video wall, simply click on the required source in the sources tab and drag it onto the display wall representation.
  • Page 9 A WallControl 10-Pro serial dongle must be inserted into a vacant USB port. If the dongle is removed or swapped, the Security Administration Client will not open and an error message is displayed, therefore it is important the dongle is not removed. The WallControl 10 Security Application help file contains information on how to: •...
  • Page 10 Whilst every effort is made to ensure that the information contained in this Quick Start Guide is correct, Datapath Limited make no representations or warranties with respect to the contents thereof, and do not accept liability for any errors or omis- sions.
