Datapath VSN400 User Manual page 36

6.4.6 WallControl 10 Security Administration Client
The WallControl 10 Security Administration Client allows Administrators to assign specific user roles on a wall by wall
basis. Users are assigned Roles based on their Windows login. Roles can be structured to allow only specific tasks to
be carried out on a wall using the WallControl 10 Client. For example, a user can be assigned a role allowing
unrestricted access on one wall but assigned a role on another wall which only allows the launching of pre-determined
layouts.
The application allows you to carry out the following User Rights Management Tasks:
Import users from the Windows Active Directory into the application database
•
Create and edit roles
•
Assign permissions to providers, layouts and sources giving specific roles access to them
•
Assign Roles to walls.
•
3 4 5
1 Indicates the server you are connected too.
2 A representation of the display wall(s) associated with the server.
3 Sources Tab - Displaying all the sources connected to the server for use on the display wall.
4 Layouts Tab - Used to save, recall and share display wall layout configurations.
5 Templates Tab - Use templates to assist in the design of specific display wall layouts.
Operation
36
Operation
1
2
